HT-R330
<Notes>
<DD> : USA model only
<DC> : Canadian model only
<WT> : World wide model only
<PP> : European model only
EXPLODED VIEW PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO (SN) REMARKS
EXP
A001 RETAINER (F) 1 27141972
EXP
A004 SCREW 3TTB+8B(CU)SR 20 801618
EXP
A003 SCREW 3TTB+8B(BC) 35 838430088
EXP
A002 SCREW 3TTB+10B(BC) 14 838430108
EXP
A010 CHASSIS --- 1 27100460A
EXP
A011 TAPE TAPE(CLOTH-16U) (1) 29110083
EXP
A013 WIRE TIE BSK-1 6 260208
EXP
A014 CLIP CS-1U 2 27255004
EXP
A015 HOLDER KGLS-14RT 3 27190524
EXP
A016 HOLDER HOLDER 2 27190991
EXP
A023 SCREW 4TTC+8C(BC) 4 830440089
EXP
A025 TAPE TAPE(CLOTH-16U) (1) 29110083
EXP
A028 BUSHING S-RELIEF #2271 1 27300750
!
EXP
A030 HEAT SINK AS. 1 27160563B
EXP
A037 SCREW 3SMS8W.SW+14B(BC) 12 801433
EXP
A040 BRACKET (U) 1 27130986
EXP
A045 SHLD PLT (R) 1 27150504
EXP
A046 PLA RIVET P3035B 1 880016
EXP
A048 CUSHION t3 x 50 x 10 2 28141563
EXP
A050 COVER --- 1 28184926
EXP
A051 SCREW 3TTB+8B(UN) 6 838930088
EXP
A052 LABEL (COVER) 1 29364123
EXP
A055 LEG LEG 4 27175319B
EXP
A056 CUSHION --- 8 28141494
EXP
A065 CLEAR PLT --- 1 28192065A
EXP
A401 REAR PANEL HT-R330MDD 1 27123405 <DD>
EXP
A401 REAR PANEL HT-R330MDD 1 27123405 <DC>
EXP
A401 REAR PANEL HT-R330MWT 1 27123406A <WT>
EXP
A401 REAR PANEL HTR330MPP 1 27123453 <PP>
EXP
A402 LABEL (WEEE) 1 29364199 <PP>
EXP
A405 F PANEL --- 1 27212768A <DD>
EXP
A405 F PANEL --- 1 27212768A <DC>
EXP
A405 F PANEL --- 1 27212768A <WT>
EXP
A405 F PANEL --- 1 27212788 <PP>
EXP
A406 FACET (ST) 1 28198998A
EXP
A411 KNOB (POW) 1 28326299
EXP
A412 KNOB (SEL) 1 28326303
EXP
A413 KNOB (PRE) 1 28326306
EXP
A420 BADGE --- 1 28135298
EXP
A425 RETAINER (BRO) 1 27141873 <PP>
EXP
A430 KNOB (VOL)AS 1 28326319
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
