26
Connecting the AV receiver—Continued
• With connection , you can listen to and record audio from a DVD.
• To enjoy Dolby Digital and DTS, use connection or . (To record as well, use and , or and .)
• If your DVD/BD player has main left and right outputs and multichannel left and right outputs, be sure to use the main
left and right outputs for connection .
Connecting a DVD/BD player
Connection AV receiver Signal flow DVD/BD player
COMPONENT VIDEO IN 1 (DVD/BD) Component video output
DVD/BD IN V Composite video output
DVD/BD IN L/R Analog audio L/R output
DIGITAL IN COAXIAL (DVD/BD) Digital coaxial output
DIGITAL IN OPTICAL 1 (CBL/SAT) Digital optical output
Step 1: Video Connection
Choose a video connection that matches your DVD/BD player ( or
), and then make the connection.
You must connect the AV receiver to your TV with the same type of connection.
A B
Step 2: Audio Connection
Choose an audio connection that matches your DVD/BD player ( , , or ), and then make the connection.
a b c
a
b c a b a c
a
A
B
a
b
c
YCOAXIAL
OUT
PB
COMPONENT VIDEO OUT
P
RAUDIO
OUT
VIDEO
OUT
LR
OPTICAL
OUT
b
c
A
C
a
B
DVD/BD player
Connect one or the other
Connection must be
assigned (see page 36)
c
To Next Page
