Onkyo HT-R500 Service Manual

HT-R500
BLOCK DIAGRAM 2
AC OUTLET
P351
Q306
OR KRA102S
C352
104Z
BASSBOOST
OPAMP
OUTPUT GAIN
0-18dB
OPAMP
OUTPUT GAIN
0-18dB
OPAMP
OUTPUT GAIN
0-18dB
OPAMP
OUTPUT GAIN
0-18dB
OPAMP
OUTPUT GAIN
0-18dB
OPAMP
OUTPUT GAIN
0-18dB
G
AIN
0/6dB
GAIN
0/6dB
G
AIN
0/6dB
GAIN
0/6dB
G
AIN
0/6dB
U
T GAIN
0/6dB
Q305
OPAMP
15dB
47/16
47/16
47/16
47/16
47/16
47/16
SEC1H RELAY
POWER
RELAY
MASTER
VOLUME
0,,-103dB
SEC2
BASS/TREBLE
BASS/TREBLE
AC IN
T901
PRI
SEC1
T902
RI
SEC3
+B1L
+B1H
HEADPHONE
+5V
DSP/TU
-12V
+12V
AF/TU
+12V
AF
-12V
+
7V
D3811
-7V
B
D3811
VOLTAGE
SENSOR
VOLH
PROTE
CTION
PRO
VOLTAGE &
CURRENT
SENSOR
VIDEO
+12V
-27V
-VP
FL TUBE
FLAC
FLAC
SEC1H
CONTROL
RELAY
+B2
SEC1H
+B1
+5.6V
STANDBY
POWER
RI
INTERFACE
SPHP
+27dB
+27dB
+27dB
+27dB
+27dB
FUSE
L
R
C
SL
SR
SPBL
SPBR
2.2K
2.2K
2.2K
2.2K
2.2K
R385
100
R388
100
270
69
68
55
66
65
57
43
42
38
40
39
37
30
31
35
33
34
36
SWPO
AMUT
SPF
SPCS
SPB
HPMUT HPDET
SELMUT
SELDA
SELCL
D
ISPLAY
Y
Power Amplifier
A
1
2
3
4
5
BCD

Onkyo HT-R500 Specifications

Amplifier Section

continuous average power output (FTC)	100 watts per channel at 8 ohms
dynamic power output at 3 ohms	230 watts × 2
dynamic power output at 4 ohms	170 watts × 2
dynamic power output at 8 ohms	115 watts × 2
total harmonic distortion	0.08% at rated power
damping factor	60 at 8 ohms

Input and Output Impedance

digital input (optical 1, 2)	0.5 Vp-p, 75 ohms
digital input (coaxial)	0.5 Vp-p, 75 ohms
line (CD, VIDEO 1, 2, 3, TAPE)	200 mV, 50 kohms
multichannel input (DVD FRONT L/C/R, SURR L/R)	200 mV, 50 kohms
subwoofer input	36 mV, 50 kohms
rec out (TAPE, VIDEO 1)	200 mV, 470 ohms
pre out (subwoofer)	1 V, 470 ohms

Tuner Section

FM tuning range	87.5-108.0 MHz
FM usable sensitivity (mono)	11.2 dBf, 1.0 µV (75 ohms, IHF)
FM usable sensitivity (stereo)	17.2 dBf, 2.0 µV (75 ohms, IHF)
FM signal-to-noise ratio (mono)	76 dB, IHF
FM signal-to-noise ratio (stereo)	70 dB, IHF
AM tuning range	530-1, 710 kHz
AM usable sensitivity	30 µV
AM signal-to-noise ratio	40 dB

General

power supply	AC 120 V, 60 Hz
power consumption	5.5 A
dimensions (W × H × D)	17-1/8” × 5-7/8” × 14-13/16”
dimensions in mm (W × H × D)	435 × 150 × 376 mm
weight	21.4 lbs.
weight in kg	9.7 kg
