AMPLIFIER SECTION
Continuous Average Power output (FTC)
All channels:
100 watts per channel min. RMS at 8 ohms,
2 channels driven from 20 Hz to 20 kHz
with no more than 0.08% total harmonic
distortion.
Dynamic power output: 230 watts × 2 at 3 ohms
170 watts × 2 at 4 ohms
115 watts × 2 at 8 ohms
Total Harmonic Distortion: 0.08% at rated power
0.08% at 1 watt output
IM Distortion: 0.08% at rated power
0.08% at 1 watt output
Damping Factor: 60 at 8 ohms
Input Sensitivity and Impedance
DIGITAL INPUT (OPTICAL 1, 2):
0.5 Vp-p, 75 ohms
DIGITAL INPUT (COAXIAL):
0.5 Vp-p, 75 ohms
LINE (CD, VIDEO 1, 2, 3, TAPE):
200 mV, 50 kohms
Multichannel Input
(DVD FRONT L/C/R, SURR L/R):
200 mV, 50 kohms
(SUBWOOFER): 36 mV, 50 kohms
Output Level and Impedance
Rec out (TAPE, VIDEO 1): 200 mV, 470 ohms
Pre out (SUBWOOFER): 1 V, 470 ohms
Frequency Response:
10 Hz to 100 kHz, +1/–3 dB (Direct mode)
Tone Control
Bass: ±12 dB at 50 Hz
Treble: ±12 dB at 20 kHz
Signal-to-Noise Ratio:
CD/TAPE: 100 dB (IHF-A, Direct mode)
Muting: –50 dB
VIDEO SECTION
Input Sensitivity and Impedance
VIDEO (DVD, VIDEO 1, 2, 3):
1 Vp-p, 75 ohms
S VIDEO (DVD, VIDEO 1, 2, 3):
1 Vp-p, 75 ohms (Y)
0.28 Vp-p, 75 ohms (C)
Output Level and Impedance
VIDEO (VIDEO 1, 2, MONITOR):
1 Vp-p, 75 ohms
S VIDEO (VIDEO 1, 2, MONITOR):
1 Vp-p, 75 ohms (Y)
0.28 Vp-p, 75 ohms (C)
TUNER SECTION
FM
Tuning Range: 87.5-108.0 MHz (50 kHz steps)
Usable Sensitivity
Mono: 11.2 dBf, 1.0 µV (75 ohms, IHF)
11.2 dBf, 0.9 µV (75 ohms, DIN)
Stereo: 17.2 dBf, 2.0 µV (75 ohms, IHF)
17.2 dBf, 23 µV (75 ohms DIN)
50 dB Quieting Sensitivity
Mono: 17.2 dBf, 2.0 µV (75 ohms)
Stereo: 37.2 dBf, 20.0 µV (75 ohms)
Capture Ratio: 2.0 dB
Image Rejection Ratio: 40 dB
IF Rejection Ratio: 90 dB
Signal-to-Noise Ratio
Mono: 76 dB, IHF
Stereo: 70 dB, IHF
Alternate Channel Attenuation: 55 dB, IHF, ±400 kHz
Selectivity: 50 dB (DIN)
AM Suppression Ratio: 50 dB
Total Harmonic Distortion
Mono: 0.2%
Stereo: 0.3%
Frequency Response: 30 Hz-15 kHz, ±1.0 dB
Stereo Separation: 45 dB at 1 kHz
30 dB at 100 Hz-10 kHz
AM
Tuning Range: 530-1,710 kHz (10 kHz steps)
Usable Sensitivity: 30 µV
Image Rejection Ratio: 40 dB
IF Rejection Ratio: 40 dB
Signal-to-Noise Ratio: 40 dB
Total Harmonic Distortion: 0.7%
GENERAL
Power Supply and Power Consumption:
AC 120 V, 60 Hz 5.5 A
Dimensions (W × H × D): 17-1/8” × 5-7/8” × 14-13/16”
435 × 150 × 376 mm
Weight: 21.4 lbs., 9.7 kg
REMOTE CONTROL
Transmitter: Infrared
Signal range: Approx. 16 ft., 5 meters
Power supply: Two “AA” batteries (1.5 V × 2)
Specifications and features are subject to change without notice.
Power supply and voltage vary depending on the area in which the unit is
purchased.
