Specifications
Amplifier Section
Video Section
Tuner Section
General
■ HDMI
■ Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
■ Others
Specifications and features are subject to change
without notice.
Rated Output Power
All channels:
1 ch × 100 W at 6 ohms, 1 kHz, 1 ch driven
(IEC)
Dynamic Power 160 W (3 Ω, Front)
125 W (4 Ω, Front)
85 W (8 Ω, Front)
THD (Total Harmonic Distortion)
0.08% (1 kHz, 1 W)
Damping Factor 60 (Front, 1 kHz, 8 Ω)
Input Sensitivity and Impedance
200 mV/47 kΩ (LINE)
Output Level and Impedance
200 mV/2.2 kΩ (REC OUT)
Frequency Response 20 Hz - 50 kHz/+1 dB, -3 dB (DSP bypass)
Tone Control Characteristies
±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 100 dB (LINE, IHF-A)
Speaker Impedance 6 Ω - 16 Ω
Input Sensitivity/Output Level and Impedance
1 Vp-p/75 Ω (Component Y)
0.7 Vp-p/75 Ω (Component PB/CB, PR/CR)
1 Vp-p/75 Ω (Composite)
Component Video Frequency Response
5 Hz - 100 MHz/+0 dB, -3 dB
FM Tuning Frequency Range
87.50 MHz - 108.00 MHz, RDS
AM Tuning Frequency Range
522/530 kHz - 1611/1710 kHz
Preset Channel 40
Power Supply AC 230 V, 50 Hz
Power Consumption 340 W
Stand-by Power Consumption
0.3 W
Dimensions
(W × H × D)
435 mm × 151.5 mm × 328.5 mm
Weight 8.0 kg
Input IN 1, IN 2, IN 3
Output OUT
Video Resolution 1080p
Audio Format Dolby TrueHD, DTS Master Audio,
DVD-Audio, DSD
Supported 3D, Audio Return Channel, Deep Color,
x.v.Color, LipSync, CEC
Component IN 1, IN 2
Composite BD/DVD, VCR/DVR, CBL/SAT, GAME
Component OUT
Composite MONITOR OUT, VCR/DVR OUT
Digital Optical: 2
Coaxial: 1
Analog BD/DVD, VCR/DVR, CBL/SAT, GAME,
TV/CD, AUX
Analog VCR/DVR
Speaker Outputs SP-A (L, R), C, SL, SR + SP-B (L, R), SW
Phones 1 (6.3 ø)
Universal Port 1
RI 1
