Specifications
18
Amplifier Section
Rated Output Power
All channels: 65 watts minimum continuous power per channel,
8 ohm loads, 2 channels driven from 20 Hz to 20 kHz, with a
maximum total harmonic distortion of 0.7% (FTC)
90 watts minimum continuous power per channel, 6 ohm loads, 2
channels driven at 1 kHz, with a maximum total harmonic distortion
of 0.7% (FTC)
(North American)
5 ch × 100 W at 6 ohms, 1 kHz,
1 ch driven of 1% (IEC) (Others)
Maximum Effective Output Power
5 ch × 120 W at 6 ohms, 1 kHz,
1 ch driven (JEITA)
(Asian)
Dynamic Power (
¼
)
¼
IEC60268-Short-term maximum output power
9ŝ(TQPV
9ŝ(TQPV
9ŝ(TQPV
THD+N (Total Harmonic Distortion+Noise)
0.7% (20 Hz - 20 kHz, half power)
Damping Factor
(TQPVM*\ŝ
Input Sensitivity and Impedance (Unbalance)
O8Mŝ.+0'
Rated RCA Output Level and Impedance
O8Mŝ.+0'176
Maximum RCA Output Level and Impedance
8Mŝ.+0'176
Frequency Response
5 Hz - 100 kHz/+1 dB, –3 dB (Direct mode)
Tone Control Characteristics
±10 dB, 20 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio
100 dB (LINE, IHF-A)
Speaker Impedance
ŝŝ
Video Section
Input Sensitivity/Output Level and Impedance
8RRŝ%QORQPGPV;
8RRŝ%QORQPGPV2
B
/C
B
, P
R
/C
R
)
8RRŝ%QORQUKVG
Component Video Frequency Response
5 Hz - 100 MHz/+0 dB, –3 dB
Tuner Section
FM Tuning Frequency Range
87.5 MHz - 107.9 MHz (North American)
87.5 MHz - 108.0 MHz, RDS (Others)
AM Tuning Frequency Range
522/530 kHz - 1611/1710 kHz
Preset Channel
40
Network Section
Ethernet LAN
10BASE-T/100BASE-TX
Wireless LAN
IEEE 802.11 b/g/n standard
(Wi-Fi
®
standard)
2.4 GHz band:
1 - 11 ch (North American)
10 - 11 ch (Spain)
10 - 13 ch (France)
1 - 13 ch (Others)
(Wi-Fi
®
standard)
Bluetooth Section
Communication system
Bluetooth Specification version 2.1 +EDR (Enhanced Data Rate)
Maximum communication range
Line of sight approx. 15 m (
¼
)
Frequency band
2.4 GHz band (2.4000 GHz - 2.4835 GHz)
Modulation method
FHSS (Freq Hopping Spread Spectrum)
Compatible Bluetooth profiles
A2DP 1.2 (Advanced Audio Distribution Profile)
AVRCP 1.3 (Audio Video Remote Control Profile)
Supported Codecs
SBC
Transmission range (A2DP)
20 Hz - 20,000 Hz (Sampling frequency 44.1 kHz)
¼
The actual range will vary depending on factors such as obstacles
between devices, magnetic fields around a microwave oven, static
electricity, cordless phone, reception sensitivity, antenna’s
performance, operating system, software application, etc.
General
Power Supply
AC 120 V, 60 Hz (North American)
AC 220 - 240 V, 50/60 Hz (Others)
Power Consumption
3.2 A (North American)
380 W (Others)
0.1 W (Stand-by, North American)
0.2 W (Stand-by, Others)
55 W (No-sound)
Dimensions (W × H × D)
435 mm × 150 mm × 329 mm
17-1/8" × 5-7/8" × 12-15/16"
Weight
7.6 kg (16.8 lbs.) (North American)
8.1 kg (17.9 lbs.) (Others)
HDMI
Input
IN1 (BD/DVD), IN2 (CBL/SAT), IN3 (STB/DVR), IN4 (GAME), IN5 (PC),
IN6
Output
OUT
Video Resolution
4K 60 Hz (YCbCr 4:2:0)
Audio Format
DTS-HD Master Audio, DTS-HD High Resolution Audio, Dolby TrueHD,
Dolby Digital Plus, DSD, Multichannel PCM
Supported
3D, Audio Return Channel, DeepColor, x.v.Color, LipSync, CEC (RIHD),
4K Passthrough
Video Inputs
Component
IN (GAME)
Composite
IN1 (CBL/SAT), IN2 (STB/DVR), IN3 (GAME), AUX
Video Outputs
Component
OUT
Composite
MONITOR OUT
Audio Inputs
Digital
OPTICAL (TV/CD)
COAXIAL 1 (BD/DVD), 2 (CBL/SAT)
Analog
BD/DVD, CBL/SAT, STB/DVR, GAME, PC, TV/CD, AUX
Audio Outputs
Analog
ZONE2 LINE OUT
2 SUBWOOFER PRE OUT
Speaker Outputs
FRONT L/R, CENTER, SURROUND L/R
Phones
PHONES (Front, ø 6.3)
Others
Setup Mic 1 (Front)
RI 1
USB 1 (Front)
Ethernet 1
Specifications and features are subject to change without notice.
