HT-R680
PACKING PROCEDURES PARTS LIS
REF. NO PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[PACKING]
A601 PAD (AS)HT-S7300 1 29092503 N <B C2MDC>
A601 PAD (AS)307C 1 29092482B <B CMDC>
A605 POLY BAG w850xd650 1 29100245 <B>
A606 TAPE (SEROHAN)NITTO NO.29 1 29110149 <B>
A608 SHEET T0.5x600x500 1 29096097 <B>
A611 TAPE (SEROHAN)NITTO NO.29 1 29110149 <B>
A704A LABEL (DES)680BMDC { 1} 29391094 N <B CMDC>
A704A LABEL (DES)680C2DC { 1} 29391172A N <B C2MDC>
[ACCESSARY]
A672 POLY BAG w250xd350 1 29100250A <B C2MDC, CMDC>
A674 POLY BAG D250xd300xW300(t0.04) 1 29100256A <B>
A676 TAPE (SEROHAN)NITTO NO.29 1 29110149 <B>
A801 INS MANUAL En(HT-S6300) 1 29400232A N <B>
A802 INS MANUAL U2FrEs(HT-S6300) 1 29400255A N <B C2MDC, CMDC>
A805 INS MANUAL En(QSS HT-S7300) 1 29400407A N <B C2MDC>
A810 INS MANUAL En(QSS HT-S6300) 1 29400233A N <B CMDC>
A823 INS MANUAL U9(2010_Prepro) 1 29400269 <B>
A826 INST SHEET U11(2010_RIHD) 1 29355782 <B C2MDC, CMDC>
A855 REMO CON RC-764M 1 24140764 <B>
A856 MIC MIC-5001 1 245043 <B>
A858 ANT COIL NMA-3057 1 232140 <B>
A859 FM ANT AS Type W 1 292191 <B>
A861 BATTERY R6/AA(UM-3) 2 3010194 <B C2MDC, CMDC>
A861 or BATTERY R6/AA(UM-3) ( 2) 3010054 <B C2MDC, CMDC>
A885 WRNTY CARD (ONKYO) 1 29365135 <B C2MDC, CMDC>
HT-R680
PC BOARD PARTS LIS
U001
F-AS(Amplifier Asy)
U0010+U0011+U0012+U0013+U0014
BAAF-0348-1A * 1 1B247548-1A N <B C2MDC, CMDC>
U0010 AF-ASAF-AS(Amplifier Asy) BAAF-0348-1A 1 1B2475348-1A N <B C2MDC, CMDC>
U0011 PWB(FL Tube -VP) BAPS-0349-1A 1 1B2475349-1A N <B C2MDC, CMDC>
U0012 PWB(Thermal Senser) BAETC-0350-1A 1 1B2475350-1A N <B C2MDC, CMDC>
U0013 WB(Thermal Senser FIX) BAETC-0351-1A 1 1B2475351-1A N, NSP <B C2MDC, CMDC>
U0014 PWB(Trans Terminal FIX) BAETC-0352-1A 1 1B2475352-1A N <B C2MDC, CMDC>
