A
672
POLY BAG
w250xd35
0
1 29100250
A
<B CMDC, CMPP>
A
673
POLY BAG
--- 1 29100225
A
<B CMPP>
A
674
POLY BAG
D250xd300xW300
(
t0.04
)
1 29100256
A
<B>
A
676
TAPE
(
SEROHAN
)
NITTO NO.29 1 29110149 <B>
A
801
INS MANUAL
U2EnFr
(
HT-R980
)
1 29400486 N <B>
A
802
INS MANUAL
Es
(
HT-R980
)
1 29400487 N <B CMDC, CMPP>
A
804
INS MANUAL
U3DeNlSv
(
HT-R980
)
1 29400488 N <B CMPP>
A
810
INS MANUAL
En
(
QSS HT-S9300THX
)
1 29400238 N <B>
A
823
INS MANUAL
U9
(
2010
_
Pre
p
ro
)
1 29400269 <B>
A
826
INST SHEET
U11
(
2010
_
RIHD
)
1 29355782 <B>
A
830
INST SHEET
WEEE 1 29355793 <B CMPP>
A
835
HANDBILL
(
UP-A1
)
US 1 29380155 <B CMDC>
A
835
HANDBILL
(
UP-A1
)
EU 1 29380156 <B CMPP>
A
855
REMO CON
RC-764M 1 24140764 <B>
A
856
MIC
MIC-7000 1 245044 <B>
A
858
A
NT COIL
NMA-3057 1 232140 <B>
A
859
FM ANT AS
T
yp
e W 1 292191 <B>
A
861
BATTER
Y
R6/AA
(
UM-3
)
2 3010194 <B CMDC, CMPP>
A
861 or
BATTER
Y
R6/AA
(
UM-3
)
(
2
)
3010054 <B CMDC, CMPP>
A
885
WRNTY CARD
(
ONKYO
)
1 29365135 <B CMDC>
HT-R980
PC BOARD PARTS LIST
U001
A
F-AS(Amplifier Asy)
U0010+U0011+U0012+U0013+U0014
BAAF-0348-1A * 1 1B247548-1A N <B CMDC>
U001
A
F-AS(Amplifier Asy)
U0010+U0011+U0012+U0013+U0014
BAAF-0348-1B * 1 1B247548-1B N <B CMPP>
U0010
A
F-AS
(
Am
p
lifier As
y)
BAAF-0348-1
A
1 1B2475348-1
A
N <B CMDC>
U0010
A
F-AS
(
Am
p
lifier As
y)
BAAF-0348-1B 1 1B2475348-1B N <B CMPP>
U0011
PWB
(
FL Tube -VP
)
BAPS-0349-1
A
1 1B2475349-1
A
N <B CMDC>
U0011
PWB
(
FL Tube -VP
)
BAPS-0349-1B 1 1B2475349-1B N <B CMPP>
U0012
PWB
(
Thermal Senser
)
BAETC-0350-1
A
1 1B2475350-1
A
N <B CMDC>
U0012
PWB
(
Thermal Senser
)
BAETC-0350-1B 1 1B2475350-1B N <B CMPP>
U0013
PWB
(
Thermal Senser FIX
)
BAETC-0351-1
A
1 1B2475351-1
A
N <B CMDC>
U0013
PWB
(
Thermal Senser FIX
)
BAETC-0351-1B 1 1B2475351-1B N <B CMPP>
U0014
PWB
(
Trans Terminal FIX
)
BAETC-0352-1
A
1 1B2475352-1
A
N <B CMDC>
U0014
PWB
(
Trans Terminal FIX
)
BAETC-0352-1B 1 1B2475352-1B N <B CMPP>
CIRCUIT PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D4171 ZENER D MTZJ6.2B 1 224470622T
D4172 ZENER D MTZJ6.2B 1 224470622T
D4173 DIODE 1SS133 1 223163T
D4174 DIODE 1SS133 1 223163T
D4207 C-DIODE KDS4148U 1 223283R2 NSP <B CMDC, B CMPP>
D4207 or C-DIODE 1SS352 ( 1) 223234R2 NSP <B CMDC, B CMPP>
D4207 or C-DIODE MA2J111 ( 1) 223279R2 NSP <B CMDC, B CMPP>
D4208 C-DIODE KDS4148U 1 223283R2 NSP
D4208 or C-DIODE 1SS352 ( 1) 223234R2 NSP
D4208 or C-DIODE MA2J111 ( 1) 223279R2 NSP
D4217 C-DIODE KDS4148U 1 223283R2 NSP <B CMDC, B CMPP>
