HT-RC260 7.2-Channel Home Theater Receiver
NPR No. 10N27 03/10
Due to a policy of continuous product improvement, Onkyo reserves the right to change specifications and appearance without notice. Manufactured under license from Dolby Laboratories. Dolby, Pro Logic, and the double-D symbol are trademarks of Dolby Laboratories. DTS is a
registered trademark and the DTS logos and Symbol are trademarks of DTS, Inc. DSX, 2EQ, Dynamic EQ, and Dynamic Volume are trademarks of Audyssey Laboratories. HDMI, the HDMI logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other countries. iPod is a trademark of Apple Inc., registered in the U.S. and other countries. iPhone is a trademark of Apple Inc. HD Radio and the HD Radio logo are trademarks of iBiquity Digital Corp. x.v.Color is a trademark of Sony
Corporation. Faroudja DCDi Cinema is a registered trademark of Genesis Microchip Inc. WRAT, Music Optimizer, CinemaFILTER, and Theater-Dimensional are trademarks of Onkyo Corporation. All other trademarks and registered trademarks are the property of their respective holders.
Onkyo Corporation
2-1 Nisshin-cho, Neyagawa-shi, Osaka 572-8540, JAPAN Tel: +81-72-831-8136 Fax: +81-72-833-5222 http://www.onkyo.com/
Onkyo U.S.A. Corporation 18 Park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: +1-201-785-2600/800-229-1687 (Toll free) Fax: +1-201-785-2650 http://www.onkyousa.com/
Mexico: Representaciones de Audio, S.A. de C.V. Calle 10 No. 133 Col. Granjas San Antonio Del. Iztapalapa C.P. 09070 Mexico, D.F. MEXICO Tel: +52-55-3300-4550 Fax: +52-55-3300-4569
Brazil: Disac Comercial Ltda Av.Brig. Faria Lima, No 1.461-Torre SUL-cj 151-154 Sao Paulo-SP BRAZIL CEP 01452-002 Tel: +55-11-3811-7272 Fax: +55-11-3811-7265 http://www.disac.com.br/
Convenient Overlaid Graphical
On-Screen Display via HDMI
Changing your A/V receiver’s settings is now more
s
eamless than ever, thanks to the HT-RC260’s new
o
verlaid graphical On-Screen Display (OSD)
feature. Simply press the Home button on the
i
ncluded remote controller, and semi-transparent
g
raphical set-up menus appear overlaid on the
video image you’re watching. This means you can
adjust the settings immediately, without having to
s
witch back and forth from a blank screen
b
ackground.
192 kHz/24-Bit Burr-Brown DACs
Improve Jitter Performance to Deliver
Clearer Sound
High-quality Burr-Brown DACs (PCM1690) work to
o
ptimize analog audio performance on the
H
T-RC260. These DACs perform advanced 24-bit
signal processing and support sampling rates of up
to 192 kHz, while displaying high resistance to clock
j
itter and offering a 113 dB dynamic range.
A Suite of Audyssey Technologies for the
Ideal Listening Environment
(
1) Audyssey 2EQ
™
t
ailors multi-channel audio for
your home theater speaker set-up by measuring
three room positions and applying a resolution
f
ilter to the satellite speakers to correct for room
a
coustics.
(2) Audyssey Dynamic Volume
™
automatically
c
ompensates for volume fluctuations in different
audio content—for example, during commercial
breaks—while optimizing the dynamic range.
(3)Audyssey Dynamic EQ
™
maintains a consistent
bass response, tonal balance, and surround-sound
effect at different volume levels, so you can enjoy
the natural dynamics of your content regardless of
the volume.
Playback of Different Audio Sources in
Two Different Zones
With Powered Zone 2, you can enjoy surround-
sound entertainment in the main room, while
playing back a different stereo source in a second
zone equipped with a pair of speakers. Alternatively,
you can use the Zone 2 line-out to send an
unamplified audio signal to an amplifier (and
speakers) in the second room.
• HDMI
®
(Version 1.4a to Support 3D and Audio Return
Channel) with Deep Color
™
, x.v.Color
™
, LipSync, Dolby
®
TrueHD, DTS-HD Master Audio
™
, DVD-Audio, Super
Audio CD, Multichannel PCM, and CEC
• Dolby
®
TrueHD, DTS-HD Master Audio
™
, Dolby
®
Digital
Plus, DTS-HD High-Resolution Audio
™
Decoding
• HDMI Video Upscaling to 1080p with Faroudja DCDi
Cinema
™
• Audyssey DSX
™
and Dolby
®
Pro Logic
®
IIz for New
Surround Channels
• Burr-Brown 192 kHz/24-Bit DACs (PCM1690) for All
Channels
• Three-Stage Inverted Darlington Circuitry
• Jitter-Cleaning Circuit Technology
• Audyssey 2EQ
™
for Room Acoustic Correction
• Audyssey Dynamic Volume
™
• Audyssey Dynamic EQ
™
for Loudness Correction
• Powered Zone 2 and Zone 2 Line-Out for Playback of
Separate Source in Another Room
• Overlaid Graphical On-Screen Display (OSD) via HDMI
• 2 Parallel Subwoofer Pre Outs
A
D
V
A
N
C
E
D
F
E
A
T
U
R
E
S
• 100 Watts per Channel at 8 Ohms, 20 Hz–20 kHz,
0
.08%, 2 Channels Driven, FTC
•
WRAT (Wide Range Amplifier Technology)
• High-Current Low-Impedance Drive
• H.C.P.S. (High Current Power Supply) Massive High
P
ower Transformer
• Optimum Gain Volume Circuitry
• Bi-Amping Capability
A
M
P
L
I
F
I
E
R
F
E
A
T
U
R
E
S
•
Advanced 32-Bit Processing DSP Chip
•
4 DSP Modes for Gaming: Rock, Sports, Action, and RPG
(Role Playing Game)
•
Music Optimizer
™
f
or Compressed Digital Music Files
•
Direct Mode
• Double Bass Function
• CinemaFILTER
™
•
Non-Scaling Configuration
•
A-Form Listening Mode Memory
• Theater-Dimensional Virtual Surround Function
P
R
O
C
E
S
S
I
N
G
F
E
A
T
U
R
E
S
• Universal Port for Single-Cable Connection of Optional
O
nkyo Dock for iPhone
™
/
iPod
®
o
r HD Radio
™
T
uner
•
Audio and 1080p Video Processing via HDMI
(1 Front/5 Rear Inputs and 1 Output)
• HDTV-Capable (720p/1080i) Component Video
Switching (2 Inputs and 1 Output)
• Front-Panel Audio Input for Portable Devices
• Front-Panel Auxiliary A/V Input
• 4 Digital Inputs (2 Optical and 2 Coaxial)
•
4 A/V Inputs and 1 Output
• Video Output (Monitor)
• 1 Audio Input
• Color-Coded, Banana Plug-Compatible Speaker Posts
• Headphone Jack
C
O
N
N
E
C
T
I
O
N
F
E
A
T
U
R
E
S
• Crossover Adjustment (40/50/60/70/80/90/100/120/150/
200 Hz)
• A/V Sync Control Function (Up to 200 ms in
10 ms Steps)
• Tone Control (Bass/Treble) for Front L/R Channels
• Display Dimmer (Normal/Dim/Dimmer)
• Sleep Timer (via Remote)
• Battery-Free Memory Backup
• 40 FM/AM Random Presets
• RIHD (Remote Interactive over HDMI) for
System Control
• Compatible with RI (Remote Interactive) Dock for iPod
• Preprogrammed RI Remote Control
OTHER FEATURES
SPECIFICATIONS
AM
PLIFIER
SE
CTION
P
ower Output
Front L/R 100 W/Ch (8 ohms, 20 Hz–20 kHz, 0.08%,
2 channels driven, FTC)
C
enter 100 W (8 ohms, 20 Hz–20 kHz, 0.08%,
2
channels driven, FTC)
S
urround L/R 100 W/Ch (8 ohms, 20 Hz–20 kHz, 0.08%,
2 channels driven, FTC)
Surround Back L/R, Front High L/R, Front Wide L/R, or Zone 2 L/R
1
00 W/Ch (8 ohms, 20 Hz–20 kHz, 0.08%,
2
channels driven, FTC)
D
ynamic Power 240 W (3 ohms, Front)
210 W (4 ohms, Front)
120 W (8 ohms, Front)
THD (Total Harmonic Distortion)
0
.08% (Rated power)
Damping Factor 60 (Front, 1 kHz, 8 ohms)
Input Sensitivity and Impedance
2
00 mV/47 k-ohms (Line)
O
utput Level and Impedance
200 mV/2.2 k-ohms (Rec out)
Frequency Response 5 Hz–100 kHz/+1 dB, -3 dB (DSP bypass)
T
one Control ±10 dB, 50 Hz (Bass)
±
10 dB, 20 kHz (Treble)
S
ignal-to-Noise Ratio 106 dB (Line, IHF-A)
Speaker Impedance 6 ohms –16 ohms
VIDEO SECTION
Input Sensitivity/Output Level and Impedance
V
ideo
1
.0 Vp–p/75
Ω
(
Component)
0.7 Vp–p/75
Ω
(Component PB/CB, PR/CR)
1.0 Vp–p/75 Ω (Composite)
Component Video Frequency Response
5
Hz–100 MHz/0 dB, -3 dB
TU
NER
SE
CTION
Tuning Frequency Range
FM 87.5 MHz–107.9 MHz
A
M 530 kHz–1,710 kHz
FM/AM Preset Memory
40 stations
GENERAL
Power Supply AC 120 V~, 60 Hz
Power Consumption 6.3 A
D
imensions (W x H x D)
1
7
1
/
8
˝
x 6
1
5
/
1
6
˝
x 12
1
5
/
1
6
˝
(435 x 176 x 329 mm)
Weight
25.4 lbs. (11.5 kg)
■ CARTON
D
imensions (W x H x D)
2
2
7
/
16
˝
x 11
1
1
/
16
˝
x 16
5
/
8
˝
(570 x 297 x 423 mm)
W
eight
3
0.9 lbs. (14.0 kg)
■ UPC CODE
(B)
751398009310
■ Supplied Accessories
• Indoor FM loop antenna • AM loop antenna • Speaker cable labels
• Speaker set-up microphone • Instruction manual • Quick start guide
• Remote controller • AA (R6) batteries x 2
