4/12 PAGE
HTP-750X
PRINTED CIRCUIT BOARD PARTS LIS
SKW-750X
U01 MAIN PC BOARD (NAAF-8829-1S)
U03 POWER TRANS. PC BOARD (NAPS-8831-1S)
CIRCUIT NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
PWB
<Note>
PWB
When replacement the following the transistor, made from the same HFE rank as the original type.
PWB
Q301 IC NJM4558L-D 1 22240293
PWB
Q501 TR 2SC2240-BL(TPE2_F) 1 2211406T
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
To Next Page
