4/11 PAGE
A104 SCREW 3SMS8W.SW+14B(3BC) 2 801433GR
A601 LABEL LABEL SHEET 1 29360840A
A602 TAPE (SEROHAN)NITTO NO.29 1 29110149
A604 TAPE TAPE(CLOTH-16U) 1 29110083
A903 SHEET 200x150t0.5 1 29095961
[TRANS COIL]
T901 P TRANS NPT-1539D 1 2301863
!
[SW TRM]
F901 FUSE 5A-UL/T-233 1 252326GR
!
F901C LABEL 5A/125V 1 29360462
P901 AC CORD AS-UC-2 1 253368BLTK
!
P901 or AC CORD AS-UC-2 ( 1) 253368AYUN
!
[OTHERS]
E801 WIRE TIE BSK-1 1 260208
[TUNER UNIT]
U001 U0010 ~ U0012 BAAF-0491-2F * 1 1B139591-2F
N
U0010 MAIN PCB AS BAAF-0491-2F 1 1B1395491-2F
N
U0011 POWER SUPPLY PCB AS BAPS-0492-2F 1 1B1395492-2F
U0012 ETC BAETC-0498-2F 1 NSP
HTP-990
PC BOARD PARTS LIST
U001 U0010 ~ U0012 BAAF-0491-2F *
1
1B139591-2F
N
U0010 MAIN PCB AS BAAF-0491-2F
1
1B1395491-2F
N
U0011 POWER SUPPLY PCB AS BAPS-0492-2F
1
1B1395492-2F
U0012 ETC BAETC-0498-2F
1
NSP
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D501 ZENER D MTZJ5.6B 1 224470562T
D601 ZENER D MTZJ3.6B 1 224470362T
D602 ZENER D MTZJ3.6B 1 224470362T
D603 DIODE 1SS133
1 223163T
To Next Page
