Onkyo K-505TX User Manual

26
STANDBY/ON
STANDBY
STEREO CASSETTE TAPE DECK
ALBUM
DOLBY NR
REV. MODE
COUNTER RESET
REC LEVEL
CD DUBBING
FADE
CASSETTE LOADING MECHANISM
REV. MODE
button [9]
(Stop) button
[9]
Reverse mode indicators [9]
Display
Index to parts and controls
For operational instructions, refer to the page indicated in square parentheses.
dB
10
6
3
0
–3
–6
–10
–20
CD DUBB
ALBUM
FADE
B
C
RL
Signal level indicator [13]
Dolby NR mode indicators [9]
Recording indicator [12]
Tape transportation indicators [9, 12]
CD dubbing indicator [17]
FADE/ALBUM indicators [17]
About the signal level indicator
The bars of the signal level indicator
correspond to the decibel levels 10,
6, 3, 0, –3, –6, –10, and –20 from
the top as indicated in the display
illustration.
Digital counter [10]/Recording level indication [13, 17]
Cassette tray [9]
REC LEVEL / buttons [13, 17]
(Reverse side play)/ (Play) buttons [9]
(Open/Close) button [9]
DOLBY NR button [9]
/ (Fast-forward/Rewind/
Skip) buttons [10, 11]
(Auto Space) button [14]
(Rec/Pause) button [12]
COUNTER RESET
button [10]
CD DUBBING buttons
ALBUM button/
FADE button [17]
STANDBY/ON
button [9]
Front panel
