1/7 PAGE
HTP-940
EXPLODED VIEWS PARTS LIS
<Notes>
<L> : Lch
<R> : Rch
<MDC> : Canadian model only
<MPP> : European model only
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
EXPLODED
SKW-940 (B) : POWERED SUBWOOFER
EXPLODED
AMPLIFIER SECTION
EXPLODED
Q515 TR 2SC5359-R 1 2203082
!
EXPLODED
Q515 or TR 2SC5359-O (1) 2203083
!
EXPLODED
Q516 TR 2SA1987-R(Q) 1 2203072
!
EXPLODED
Q516 or TR 2SA1987-O (1) 2203073
!
EXPLODED
Q541 TR 2SC3423-Y 1 2202104
EXPLODED
Q541 or TR 2SC3423-O (1) 2202103
EXPLODED
<Note>
EXPLODED
When replacement the following the transistor, made from the same HFE rank as the original type.
EXPLODED
Q515, Q516, Q541
EXPLODED
A01 HEAT SINK 230 1 27160591
EXPLODED
A02 CUSHION --- 2 28141682
EXPLODED
A03 CUSHION --- 1 28141691
EXPLODED
A05 SCREW 3TTB+8B(3BC) 10 838430088GR
EXPLODED
A07 ISO SHEET AC262 2 223025
EXPLODED
A08 SCREW 3SMS8W.SW+14B(CU) 2 801634
EXPLODED
A11 RETAINER (PCB) 1 27142025
EXPLODED
A101 REAR PANEL (MDC) 1 27123587A <MDC>
EXPLODED
A101 REAR PANEL (MPP) 1 27123588A <MPP>
EXPLODED
A102 BUSHING S-RELIEF #2271 1 27300750
!
EXPLODED
A103 KNOB (VOL) 1 28326463
EXPLODED
F901 FUSE 5A-UL/T-233 1 252326GR ! <MDC>
EXPLODED
F901 FUSE 1.6A-SE-EAK IECFUSE 1 252073GR ! <MPP>
EXPLODED
F901 or FUSE 1.6A-SE-TL250V (1) 252273GR ! <MPP>
EXPLODED
P901 AC CORD AS-UC-2 1 253333VOL ! <MDC>
EXPLODED
P901 or AC CORD AS-UC-2 ( 1) 253368LTK ! <MDC>
EXPLODED
P901 or AC CORD AS-UC-2 ( 1) 253368YUN ! <MDC>
EXPLODED
P901 AC CORD AS-CEE 1 253336VOL ! <MPP>
EXPLODED
S901 RC SW NRC-11007P 1 25065620 ! <MPP>
EXPLODED
T901 P TRANS NPT-1539D 1 2301863 ! <MDC>
EXPLODED
T901 P TRANS NPT-1539P 1 2301864 ! <MPP>
EXPLODED
U01 MAIN PC BOARD ASS'Y NAAF-8829-1D 1 1B138529-1D <MDC>
EXPLODED
U01 MAIN PC BOARD ASS'Y NAAF-8829-1C 1 1B138529-1C <MPP>
EXPLODED
U03
POWER TRANS. PC BOARD ASS'Y
NAPS-8831-1D 1 1B138531-1D <MDC>
EXPLODED
U03
POWER TRANS. PC BOARD ASS'Y
NAPS-8831-1C 1 1B138531-1C <MPP>
EXPLODED
U05
POWER SWITCH PC BOARD ASS'Y
NASW-8833-1C 1 1B138533-1C <MPP>
EXPLODED
U06 HOLDER PC BOARD NAETC-8834 1 --- NSP
EXPLODED
SPEAKER SECTION (SKW-940)
EXPLODED
SP01a CABINET ASS'Y SKW-940 (B) MDC 1 000-SKW940BMDCSER <MDC>
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
