EXPLODED
SP12 SCREW 4 x 25 W12-ED BLK (FOR P-TRANS) 4 412-DE40250B1
EXPLODED
SP13 CUSHION RUBBER PAD 14 x 89 T2 RUBBER (FOR P-TRANS) 2 442-902123-00
EXPLODED
SKF-540F (B) <L> / <R> : FRONT SPEAKERS
EXPLODED
--- COMPLETE UNIT SKF-540F (B) <L> 1 000-SKF540FLB <L>
EXPLODED
--- COMPLETE UNIT SKF-540F (B) <R> 1 000-SKF540FRB <R>
EXPLODED
SP21a CABINET ASS'Y SKF-540F (B) <L> 1 000-SKF540FBLSER <L>
EXPLODED
SP21b CABINET ASS'Y SKF-540F (B) <R> 1 000-SKF540FBRSER <R>
EXPLODED
SP22 CATCHING HOLDER --- 4 230-S79001B-00
EXPLODED
SP23 WOOFER W1278A (ONKYO ELE) 2 W1278A
EXPLODED
SP24 TWEETER --- 1 302-D1F5400200
EXPLODED
SP25 PANEL --- 1 D200-F54001S-10
EXPLODED
SP26 SCREW 4/16 PAN AB, ED 12 411-PE4016AB2
EXPLODED
SP27 SCREW 3.5/14 PAN P, ED 4 411-PE35140P2
EXPLODED
SP28 S. ABSORBER 25T x 60 x 60 1 443-925402-00
EXPLODED
SP29 CUSHION PANEL 1.5T x 80Dia. x 91Dia. 1 442-215107-00
EXPLODED
SP30 CUSHION TW 4T x 49.5Dia x 76Dia. 1 442-904102-00
EXPLODED
SP31 NETWORK ASS'Y --- 1 310-SKF530-02
EXPLODED
SP32a TERMINAL WHITE / BLACK 1 332-LY104B-40 <L>
EXPLODED
SP32b TERMINAL RED / BLACK 1 332-LY104B-00 <R>
EXPLODED
SP33a SPEC LABEL (L) --- 1 600-KF540L-00 <L>
EXPLODED
SP33b SPEC LABEL (R) --- 1 600-KF540R-00 <R>
EXPLODED
SP34a CLOTH FRAME ASS'Y (WITH GRILLE CLOTH and LOGO) 1 D201-F54001B-90
EXPLODED
SKC-540C (B) : CENTER SPEAKER
EXPLODED
--- COMPLETE UNIT SKC-540C (B) 1 000-SKC540CB
EXPLODED
SP41a CABINET ASS'Y SKC-540C (B) 1 000-SKC540CBSER
EXPLODED
SP42 CATCHING HOLDER --- 4 230-S79001B-00
EXPLODED
SP43 WOOFER W1278A (ONKYO ELE) 2 W1278A
EXPLODED
SP44 TWEETER --- 1 302-D1F5400200
EXPLODED
SP45 PANEL --- 1 D200-F54001S-10
EXPLODED
SP46 SCREW 4/16 PAN AB, ED 12 411-PE4016AB2
EXPLODED
SP47 SCREW 3.5/14 PAN P, ED 4 411-PE35140P2
EXPLODED
SP48 S. ABSORBER 25T x 60 x 60 1 443-925402-00
EXPLODED
SP49 CUSHION PANEL 1.5T x 80Dia. x 91Dia. 1 442-215107-00
EXPLODED
SP50 CUSHION TW 4T x 49.5Dia x 76Dia. 1 442-904102-00
EXPLODED
SP51 NETWORK ASS'Y --- 1 310-SKF530-02
EXPLODED
SP52 TERMINAL GREEN / BLACK 1 332-LY104B-30
EXPLODED
SP53 SPEC LABEL --- 1 600-SKC540-00
EXPLODED
SP54a CLOTH FRAME ASS'Y (WITH GRILLE CLOTH and LOGO) 1 D201-C54001B-90
EXPLODED
SKM-540S (B) <L> / <R> : SURROUND SPEAKERS
EXPLODED
SP61a COMPLETE UNIT "SKM-540S (B) <L>" 1 000-SKM540SLBSER <L>
EXPLODED
SP62 SPEC LABEL (L) --- 1 600-KM540L-00 <L>
EXPLODED
SP63a COMPLETE UNIT "SKM-540S (B) <R>" 1 000-SKM540SRBSER <R>
EXPLODED
SP64 SPEC LABEL (R) --- 1 600-KM540R-00 <R>
EXPLODED
SKB-540 (B) <L> / <R> : SURROUND BACK SPEAKERS
EXPLODED
SP65a COMPLETE UNIT "SKB-540 (B) <L>" 1 000-SKB540BLBSER <L>
EXPLODED
SP66 SPEC LABEL (L) --- 1 600-KB540L-00 <L>
EXPLODED
SP67a COMPLETE UNIT "SKB-540 (B) <R>" 1 000-SKB540BRBSER <R>
EXPLODED
SP68 SPEC LABEL (R) --- 1 600-KB540R-00 <R>
