3/7 PAGE
PRINTED CIRCUIT BOARD PARTS LIS
SKW-540
U01 MAIN PC BOARD (NAAF-8829-1A)
U03 POWER TRANS. PC BOARD (NAPS-8831-1A)
CIRCUIT NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
PWB
<Note>
PWB
When replacement the following the transistor, made from the same HFE rank as the original type.
PWB
Q301 IC NJM4558L-D 1 22240293
PWB
Q501 TR 2SC2240-BL(TPE2_F) 1 2211406T
PWB
Q502 TR 2SC2240-BL(TPE2_F) 1 2211406T
PWB
Q503 TR 2SC2240-BL(TPE2_F) 1 2211406T
PWB
Q505 TR KTA1024-Y 1 2215844T
PWB
Q505 or TR 2SA949-Y(TPE6_F) (1) 2211354T
PWB
Q505 or TR 2SA949-O(TPE6_F) (1) 2211353T
PWB
Q506 TR 2SC2229-Y(TPE6_F) 1 2211634T
PWB
Q506 or TR 2SC2229-O(TPE6_F) (1) 2211633T
PWB
Q507 TR 2SA949-Y(TPE6_F) 1 2211354T
PWB
Q507 or TR 2SA949-O(TPE6_F) (1) 2211353T
PWB
Q507 or TR KTA1024-Y (1) 2215844T
PWB
Q509 TR KTA1024-Y 1 2215844T
PWB
Q509 or TR 2SA949-Y(TPE6_F) (1) 2211354T
PWB
Q509 or TR 2SA949-O(TPE6_F) (1) 2211353T
PWB
Q510 TR KTC3206-Y 1 2215854T
PWB
Q510 or TR 2SC2229-Y(TPE6_F) (1) 2211634T
PWB
Q510 or TR 2SC2229-O(TPE6_F) (1) 2211633T
PWB
Q513 TR KTD2061-Y 1 2203434
PWB
Q513 or TR 2SC5171(ONK_Q) (1) 2203010
PWB
Q514 TR KTB1369-Y 1 2203424
PWB
Q514 or TR 2SA1930(ONK_Q) (1) 2203000
PWB
Q517 TR 2SA933S-S 1 2213355T
PWB
Q517 or TR 2SA933S-R (1) 2213354T
PWB
Q517 or TR KTA1267-GR (1) 2215995T
PWB
Q518 TR 2SC2235-Y(TPE6_F) 1 2211654T
PWB
Q519 TR 2SA965-Y(TPE6_F) 1 2211644T
PWB
Q602 TR KRC103M 1 2215810T
PWB
Q602 or TR DTC124ES (1) 2213160T
PWB
Q603 TR 2SC1740S-S 1 2213285T
PWB
Q603 or TR 2SC1740S-R (1) 2213284T
PWB
Q603 or TR KTC3199-GR (1) 2215864T
PWB
Q604 TR 2SA933S-S 1 2213355T
PWB
Q604 or TR 2SA933S-R (1) 2213354T
PWB
Q604 or TR KTA1267-GR (1) 2215995T
PWB
Q605 TR 2SA933S-S 1 2213355T
PWB
Q605 or TR 2SA933S-R (1) 2213354T
PWB
Q605 or TR KTA1267-GR (1) 2215995T
PWB
Q606 TR KRA103M 1 2215780T
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
To Next Page
