Speaker combinations
• Up to two powered subwoofers can be connected in either combination.
Speaker
Channels
FRONT CENTER SURROUND
SURROUND
BACK
HEIGHT 1 HEIGHT 2
Bi-AMP (*1)
ZONE 2 (*1)
(ZONE
SPEAKER)
ZONE 3 (*1)
(ZONE
SPEAKER)
2.1 ch
3.1 ch
4.1 ch
5.1 ch
6.1 ch
7.1 ch
2.1.2 ch
(*2) (*3) (*3) (*2)
3.1.2 ch
(*2) (*3) (*3) (*2)
4.1.2 ch
(*2) (*3) (*3) (*2)
5.1.2 ch
(*2) (*3) (*3) (*2)
6.1.2 ch
7.1.2 ch
4.1.4 ch
5.1.4 ch
(*1) The Bi-AMP and ZONE speakers cannot be used simultaneously.
(*2) When using the ZONE 2 speakers, it is necessary to connect the ZONE 2 speakers to the HEIGHT 1 terminals, and the height speaker to the SURROUND BACK
terminals.
(*3) When using the Bi-AMP speakers, it is necessary to connect the Bi-AMP speakers to the HEIGHT 1 terminals, and the height speaker to the SURROUND BACK
terminals.
About the HEIGHT 1/HEIGHT 2
When connecting 2 sets of the height speakers, the combination of the height speakers that can be selected is as follows.
– Height 1 Speaker: Top Middle, Height 2 Speaker: Rear High
– Height 1 Speaker: Front High; Height 2 Speaker: One of Rear High/Top Middle/Top Rear/Dolby Enabled Speaker (Surround)
– Height 1 Speaker: Top Front or Dolby Enabled Speaker (Front), Height 2 Speaker: One of Rear High/Top Rear/Dolby Enabled Speaker (Surround)
When only 1 set of the height speakers is connected, 1 from the height speakers types can be selected.
