Features
Amplification
• 65 W/channel into 6 ohms (20 Hz–20 kHz, 0.7%,
FTC)
• 90 W/channel into 6 ohms (1 kHz, DIN)
• 110 W/channel into 6 ohms (JEITA)
• Optimum Gain Volume Circuitry
• Massive High Current Power Supply (H.C.P.S.) trans-
former
Processing
• Dolby
*1
Digital and Dolby Pro Logic II
• DTS and DTS Neo:6
*2
5.1
• CinemaFILTER
• Non-Scaling Configuration
• A-Form — Auto Format Sensing
• 192 kHz/24-bit D/A converters
•Powerful and highly accurate Analog Devices 32-bit
DSP processing
• Double bass function
• Direct mode
Connections
• HDTV-ready component video switching (3 inputs, 1
output)
•3 digital inputs (2 optical, 1 coaxial, 3 assignable)
• Speaker A/B terminal
• Color-coded speaker terminal posts
• Color-coded 5.1 multichannel inputs and subwoofer
pre out
Miscellaneous
• Adjustable crossover (40/50/60/80/100/120/150/
200 Hz)
• Compatible with RI dock for the iPod
• Late night mode
• 3-Mode display dimmer
• Full-Function RI remote control
Contents
Important Safety Instructions.................2
Precautions ..............................................3
Supplied Accessories ............................. 4
Features....................................................5
Front & Rear Panels ................................6
Before Using the AV receiver................... 9
Remote Controller .................................10
Enjoying Home Theater ........................17
Connecting Your Speakers...................18
Connecting Antenna .............................20
Connecting Your Components .............. 22
Turning On .............................................32
First Time Setup ....................................33
Playing Your AV Components..............36
Using the Tuner .....................................38
Common Functions...............................42
Using the Listening Modes...................45
Adjusting the Listening Modes ............48
Recording...............................................50
Advanced Setup ....................................51
If you can’t resolve an issue, try resetting the AV
receiver by holding down the [VIDEO 1] button
and pressing the [STANDBY/ON] button.
*1. Manufactured under license from Dolby Laboratories.
“Dolby”, “Pro Logic” and the double-D symbol are regis-
tered trademarks of Dolby Laboratories.
*2. “DTS” and “Neo:6” are trademarks of Digital Theater Sys-
tems, Inc.
Introduction
Connection
Turning On & First Time Setup
Basic Operation
Enjoying the Listening Modes
Advanced Operation
Troubleshooting .................................... 55
Specifications........................................ 58
