Onkyo TX-SR503E Service Manual

1/51 PAGE
TX-SR503/503E/8350
<Notes>
(B) : Black model only <DD> : TA-SR503 USA model only
(S) : Silver model only <DC> : TX-SR503 Canadian model only
(G) : Golden model only <PP> : TX-SR503E European model only
<PA> : TX-SR503 Australian model only
<WT> : TX-SR503 World wide model only
<GR> : TX-SR503 Chinese model only
<GQ> : TX-SR503 Hong kong model only
<GK> : TX-SR503 Korean model only
<8350> : TX-SR8350 Chinese model only
EXPLODED VIEW PARTS LIS
T
REF. NO. NAME DESCRIPTION Q'TY PART NO REMARKS
EXP
A001 F BRACKET TX-SR503(B)MDD 1 27111389 (B)
EXP
A001 F BRACKET TX-SR503(S)MDC 1 27111391 (S)
EXP
A001 F BRACKET TX-SR503(G)MGR 1 27111394 (G)
EXP
A002 SCREW 3TTB+8B(CU)SR 54 801618
EXP
A005 KNOB (SEL-L) 1 28326308 (B)
EXP
A005 KNOB (SEL-L) 1 28326311 (S)
EXP
A005 KNOB (SEL-L) 1 28326310 (G)
EXP
A006 KNOB (SEL-R) 1 28326312 (B)
EXP
A006 KNOB (SEL-R) 1 28326315 (S)
EXP
A006 KNOB (SEL-R) 1 28326314 (G)
EXP
A007 FACET (ST) 1 28198998A
EXP
A013 WIRE TIE BSK-1 12 260208
EXP
A014 CLIP CS-1U 2 27255004
EXP
A015 CHASSIS --- 1 27100460A
EXP
A017 TAPE TAPE(CLOTH-16U) (1) 29110083
EXP
A018 HOLDER KGLS-22S 1 27190369
EXP
A020 HOLDER KGLS-14RT 3 27190524
EXP
A021 HOLDER HOLDER 2 27190991
EXP
A022 BRACKET (B) 1 27130987
EXP
A030 SCREW 4TTC+8C(3BC) 4 830440089GR
EXP
A033 LABEL (PT) 1 29363379-1
EXP
A041 BUSHING S-RELIEF #2271 1 27300750
!
EXP
A043 HEAT SINK AS 1 27160564A
EXP
A044 TAPE TAPE(CLOTH-16U) (1) 29110083
EXP
A046 BRACKET BRACKET 2 27130745
EXP
A049 SCREW 3SMH10W.SW+15B(CU) 14 801606
EXP
A050 IB CUSHION W15x3t TAPE (1) 28141585
EXP
A051 TAPE TAPE(CLOTH-16U) (1) 29110083
EXP
A052 BRACKET (U) 1 27130986A
EXP
A054 CUSHION (RE) 1 28141632
EXP
A056 CUSHION t3x50x10 1 28141563
EXP
A060 COVER --- 1 28184920 (B)
EXP
A060 COVER --- 1 28184926 (S)
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PAR
T
NUMBER SPECIFIED.
