TX-SR604/E604/8460
Specifications
Amplifier Section
Video Section
Tuner Section
FM
AM
General
Video Inputs
Video Outputs
Audio Inputs
Audio Outputs
Specfications and features are subject to change without
notice.
Rated Output Power (FTC)
All channels: 90 watts minimum continuous power
per channel, 8 ohm loads, 2 channels
driven from 20 Hz to 20 kHz, with a
maximum total harmonic distortion of
0.08%
110 watts minimum continuous power
per channel, 8 ohm loads, 2 channels
driven at 1 kHz, with a maximum total
harmonic distortion of 0.9%
115 watts minimum continuous power
per channel, 6 ohm loads, 2 channels
driven at 1 kHz, with a maximum total
harmonic distortion of 0.1%
Rated Output Power (IEC)
7 ch
× 150 W at 6 ohms, 1 kHz, 1 ch
driven
Maximum Output Power (JEITA)
7 ch
× 185 W at 6 ohms, 1 kHz, 1 ch
driven
Dynamic Power 225 W + 225 W (3 ohm
, Front)
170 W + 170 W (4 ohm
, Front)
105 W + 105 W (8 ohm
, Front)
THD (Total Harmonic
Distortion) 0.08% (Power Rated)
Damping Factor 60 (Front, 1 kHz, 8 ohm
)
Input Sensitivity and
Impedance 200 mV/47 k ohm (LINE)
Output Level and
Impedance 200 mV/470 ohm (REC OUT)
Frequency Response
10 Hz - 100 kHz/+1 dB - 3 dB (Direct mode)
Tone Control ±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 106 dB (LINE, IHF-A)
Speaker Impedance North American: 6 ohm -16 ohm
Others: 4 ohm -16 ohm or 6 ohm -16 ohm
Input Sensitivity/Output
Level and Impedance 1 Vp-p/75 ohm
(Component and S-Video Y)
0.7 Vp-p/75 ohm
(Component P
B/CB, PR/CR)
0.28 Vp-p/75 ohm (S-Video C)
1 Vp-p/75 ohm (Composite)
Component Video
Frequency Response 5 Hz - 50 MHz
Tuning Frequency Range
North American: 87.5 MHz - 107.9 MHz
Others: 87.5 MHz - 108.0 MHz
Usable Sensitivity Stereo: 22.2 dBf (75 ohm IHF)
Mono: 15.2 dBf (75 ohm
IHF)
Signal to Noise Ratio Stereo: 67 dB (IHF-A)
Mono: 73 dB (IHF-A)
THD Stereo: 0.5% (1 kHz)
Mono: 0.3% (1 kHz)
Frequency Response 30 Hz - 15 kHz/±1 dB
Stereo Separation 40 dB (1 kHz)
Tuning Frequency
Range North American: 530 kHz - 1710 kHz
European: 522 kHz - 1611 kHz
Others: 522/530 kHz - 1611/1710 kHz
Usable Sensitivity 300 µV/m
Signal to Noise Ratio 40 dB
THD 0.7%
Power Supply North American: AC 120 V, 60 Hz
European: AC 230 - 240 V, 50 Hz
Others: AC 120/220 - 240 V, 50/60 Hz
AC 220 - 230 V, 50/60 Hz
Power Consumption North American: 7 A
European: 630 W
Others: 630/670 W
Standby Power
Consumption North American: 0.1 W
European: 0.3 W
Others: 0.5 W
Dimensions
(W
× H × D) 435 × 174 × 377 mm
17-1/8"
×
6-7/8"
×
14-13/16"
Weight 11.4 kg
25.1 lbs.
HDMI IN1, IN2
Component IN1, IN2, IN3
S-Video DVD, VIDEO1, VIDEO2, VIDEO 3,
VIDEO4
Composite DVD, VIDEO1, VIDEO2, VIDEO3,
VIDEO4
HDMI OUT
Component OUT
S-Video MONITOR, VIDEO1, VIDEO2
Composite MONITOR, VIDEO1, VIDEO2
Digital Inputs Optical: 4 (1 on Front Panel)
Coaxial: 2
Analog Inputs DVD (MULTICHANNEL), VIDEO1,
VIDEO2, VIDEO3, VIDEO4, TAPE, CD
Multichannel Inputs 7.1
Digital Output 1
Analog Outputs TAPE, VIDEO1, VIDEO2, ZONE2
Subwoofer Pre Output 1
Speaker Outputs L, R, C, SL, SR, SBL, SBR,
ZONE2 (L/R)
Phones 1
IR Input 1
12V Trigger Out
1 (ZONE2)
