Orbit B-hyve User Manual

7
Timer Installation Timer Installation–Connecting to WIFI
Plug in your Orbit® B-hyve™ timer
Once your Orbit® timer is plugged into the
power source, it will automatically look to
pair with your smart device. In the top left
corner of the timer screen the “wifi” icon
will begin a graduated blinking sequence.
This indicates that your timer is ready to
pair with a smart device.
Install the Orbit® B-hyve™ app and
create an account on your smart device
Find Orbit_SmartHome_XXXX
in your wifi list
The B-hyve™ timer will create its own
network that will appear in your list of
available wifi connections on your smart
device. Connect to the Orbit SmartHome
network and then return to the Orbit®
B-hyve™ app.
Enter your wifi settings
After returning to the app, you will see
a list of available networks. Choose your
network and then enter the password for
the network to connect your timer to your
wifi signal. When connected, the wifi icon
on the timer will stop blinking and show
solid lines.
Keyhole
Pre-formed
Mounting Holes
No. 8 Screw
Wall
1/8"
Bottom View
Note: We recommend you consult an electrician for hardwired installations.

Orbit B-hyve Specifications

Power

rated input voltage (Australia)	240V AC
rated input voltage (Europe)	230V AC
rated input voltage (USA)	120V AC
rated input current	0.15A
max load (AUS & EU)	24V AC 1 Amp
max load (USA)	24V AC 750 mA

Operating Environment

operating temperature range	32-167° F (0-75° C)
storage temperature range	32-176° F (0-80° C)
operating humidity range	0–80%
storage humidity range	0–90%
altitude	6, 500' (2, 000 meters)
