Orbit JETRONIC-BOX User Manual

Orbit JETRONIC-BOX – Manual 1.2
6:TEST-DEVICES – Testing the System Settings without Remote Control
60:RC1-SIM
Simulates an ON/OFF signal at the RC1 input, as if you would use the switch on the transmitter.
Range: ON (high) / OFF (low)
Default setting: value of 21:RC1-PRESET
61:RC2-SIM
Simulates an ON/OFF signal at the RC2 input, as if you would use the switch on the transmitter.
Range: ON (high) / OFF (low)
Default setting: value of 23:RC2-PRESET
62:AIR-FAIL~SIM
Simulates a pressure loss at the air connector, as if the air pressure would drop below the value
14:AIR-FAIL (BOX-SETUP).
Range: NOMINAL / FAIL
Default setting: NOMINAL
