Orbit JETRONIC-BOX – Manual 1.2
1:BOX-SETUP – Basic Settings for the Box
10:R/C-BATTERY
Specifies the type of battery used (required for a correct voltage display).
Ni = NiCd or NiMh, Li = lithium ion
Default setting: Ni4 (4.8V)
11:INFO-LED
Specifies the display function for the info LED on the top side of the device.
OFF: No info LED function
RC1: Status of the RC1 remote control input: ON / OFF / NO signal => LED flashes.
RC2: Status of the RC2 remote control input: ON / OFF / NO signal => LED flashes.
Or display of the position switches if 20:RC2-MODE is set to POS.-SWITCH.
AIR: Air pressure display via modulated flashing of the LED between 14:AIR-FAIL (LED => OFF)
and 15:AIR-NOMINAL (LED => ON).
ON: Info LED always on
Default setting: RC1
12:EDT~LEFT
13:EDT~RIGHT
Selects the display function for the left or right display area on the EDT.
RC1: Remote control input RC1 – range: ON / OFF / NO
A ! marks the signal as FAIL signal, controlled by 14:AIR-FAIL and 24:@AIR-FAIL.
A * marks the signal as preset-defined, configured by 21:RC1-PRESET.
RC2: Remote control input RC2 – range: ON / OFF / NO
A ! marks the signal as FAIL signal, controlled by 14:AIR-FAIL and 24:@AIR-FAIL.
A * marks the signal as preset-defined, configured by 23:RC2-PRESET.
AIR[bar]: Air pressure display in bar (kg/cm
2
) – range: 0.0 – 10.0 bar
A ! marks the signal as FAIL signal, i.e. pressure dopped below 14:AIR-FAIL.
AIR[psi]: Air pressure display in psi (lb/inch
2
) – range: 0 – 145 psi
A ! marks the signal as FAIL signal, i.e. pressure dopped below 14:AIR-FAIL.
RC3/4/5: Output RC3/4/5 as servo travel in % – range: ±150 %
Default setting: RC1 und AIR[bar]
14:AIR-FAIL
Specifies the minimum air pressure for the LED display (11:INFO-LED) as well as the safety
setting (24:@AIR-FAIL).
This parameter should be set to the minimum pressure value where the landing gear is still able to
extend and lock safely.
Range: 0.0 bar – 15:AIR-NOMINAL
Default setting: 5.0 bar
8
