Daily Maintenance
It is recommended that you maintain the equipment as the below chart:
Maintain Every day Every week Every three months
Check: joint, pinning bolt,
pinning bolt of weight stack
√
Clean: sofa and cover
√
Lubricate: Moving and rotating
position.
√
Check if the bolts are tightened
√
Check if the cable wire is loose or
damaged
√
Lubricate: bearing and bearing
seat
√
4 box of 4; box size: 675*365*270mm
PART NO.
DESCRIPTION QTY.
PART NO.
DESCRIPTION QTY.
19/54
Chest-extension
frame
1
33/32
Adjusting board/P
ulling
fixing cover
2
7
Chest-extension
rotating frame
1
11
Handlebar tube (pedaling
tube)
3
46 Plastic briquetting
1
18/49
Backrest adjusting bushing
1
39 Leg-kicking frame
1
51 Bumper 2
14
Double pulley fork
1
63/64/65/
66/67
Cable 5
15
Wide si
ngle pulley
fork
1
38 Bearing base 2
21 Double pulley slice
1
25 Rotating bearing 1
12/17/45
Narrow single
pulley fork
1
13 Oriented hook 1
79 Tube 2
50 Fixing tube nip 2
6 Leader top tube 1
37
Leg-
extension connecting
cover
1
26 Pulley fixing frame
1
