10
ENGLISH
Insert tube and push down until the tube is seated. Make sure O-ring is in place against
fan housing opening.
To nish reassembly, replace and tighten collar clockwise until collar locking tabs are
locked in place.
Note: Many times blockage occurs due to a full disposable inner bag causing dirt to
back down the air ow system. When that happens, the blockage will be at the top of the
system, starting in the area where the disposable inner bag connects to the connector
assembly. If the above actions do not correct the problem, contact an Oreck authorized
service center or call the customer service center.
US: 1-800-989-3535
Canada: 1-888-676-7325
5
General Use
&
Maintenance
continued
4
5
4
To Next Page
Need help?
General
