Orion Cobalt CO300.2 User Manual

© 2007 directed electronics—all rights reserved 13
SPECIFICATIONS
Amplifier Section CO300.2 CO600.2
Power Output in Watts RMS, 4 Ohms 60 x 2 100 x 2
Power Output in Watts RMS, 2 Ohms 80 x 2 155 x 2
Distortion at Rated Power < 0.5% THD+N < 0.7% THD+N
Frequency Response 20Hz to 30kHz
+/-0.5dB
20Hz to 30kHz
+/-0.5dB
Linear Bandwidth 20Hz to 20kHz
±3dB
20Hz to 20kHz
±3dB
Damping Factor > 100 > 100
Input Sensitivity 175mV - 8V 175mV - 8V
Input Impedance > 15k > 10k
Fuse Type (1) 25 Amp, ATC (2) 20 Amp, ATC
Dimensions 2.1" x 8.1" x 7.9" 2.1" x 8.1" x 11.4"
Weight 4.5 lbs. 6.3 lbs.
Crossover Section
Low Pass and Hi-pass crossover Continuously variable/
2nd Order
Continuously variable/
2nd Order
Crossover Frequency Range 50Hz to 500Hz 50Hz to 500Hz
Continuous 2 load 20Hz to 200Hz, < 0.1% THD, with input voltage at 13.8VDC
