5
2.3. CS-F18DB4E5 CU-J34DBE5
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
2. Heating capacities are based on indoor temperature of 20°C D.B. (68°F D.B.) and outdoor air temperature of 7°C D.B. (44.6°F
D.B.), 6°C W.B. (42.8°F W.B.)
ELECTRICAL DATA (50 Hz)
ITEM / MODEL Indoor Unit Outdoor Unit
Main Body CS-F18DB4E5 × 2 CU-J34DBE5
Panel CZ-BT03P
Remote
Control
CZ-RD513C (Wired)
CZ-RL513B (Wireless)
Cooling Capacity kW 10.0
BTU/h 34,100
Refrigerant Charge-less m 30
Standard Air Volume for High,
m
3
/min
20 103
cfm 706 3634
Outside Dimension (H x W x D) mm 246 × 840 × 840 1170 × 900 × 320
inch 9-11/16 × 33-1/24 × 33-1/24 46-1/16 × 35-7/16 × 12-19/32
Net Weight kg (lbs) 26 (57) 92 (203)
Piping
Connection
Refrigerant Gas mm (inch) O.D Ø 12.70 (1/2) Flared Type
Liquid mm (inch) O.D Ø 6.35 (1/4) Flared Type
Drain O.D Ø 20 I.D Ø 20
Compressor Type, Number of Set - Hermetic, 1
Starting Method - Permanent Split Capacitor
Motor Type - 2-pole 1 phase brushless motor
Rated Output kW - 3.0
Fan Type, Number of Set Turbo fan-1 Mix flow fan,1
Motor Type 8-pole DC motor 6-pole single phase induction motor
Rated Output kW 0.04 0.07 × 2
Air-heat Exchanger (Row x Stage x FPI) Louver-fin type (1 × 10 × 20) Corrugate-fin type (1 × 44 × 21)
Refrigerant Control - Expansion Valve
Refrigerant Oil (Charged)
cm
3
- DAPHNE FVC68D (1500)
Refrigerant (Charged) R410a kg (oz) - 1.70 (60)
Running
Adjustment
Control Switch Wireless or Wired Remote Control -
Room Temperature Thermostat -
Noise Level dB (A) Cooling: 35/32 55/-
Power Level
dB
Cooling: 50/47 69/-
Moisture Removal L/h (Pt/h) 6.0 (12.6)
EER W/W 2.58/2.54/2.51
ITEM / MODEL Condition by ISO5151
Volts V 220 230 240
Phase Single Single Single
Power Consumption kW Cooling 3.88 3.93 3.98
Running Current A Cooling 17.8 18.1 18.4
Starting Current A 92 95 98
Power Factor % Cooling 99 94 90
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power source AC, 1~220V,230V, 240V 50Hz
