3
2 Specifications
2.1. Product Specification
2.1.1. CS-F28DTE5 CU-L50DBE5 (For Australia only)
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
2. Heating capacities are based on indoor temperature of 20°C D.B. (68°F D.B.) and outdoor air temperature of 7°C D.B. (44.6°F
D.B.), 6°C W.B. (42.8°F W.B.)
ELECTRICAL DATA (50 Hz)
ITEM / MODEL
Indoor Unit Outdoor Unit
Main Body CS-F28DTE5 x 2 CU-L50DBE5
Remote
Control
CZ-RD513C (Wired)
CZ-RL513T (Wireless)
Cooling Capacity kW 14.0
BTU/h 47,700
Heating Capacity kW 16.0
BTU/h 54,600
Refrigerant Charge-less m 30
Standard Air Volume for High,
m
3
/min
Hi 18 x 2 Me 16 Lo 14 Hi 98
Medium and Low Speed cfm 636 x 2 565 495 3460
Outside Dimension (H x W x D) mm 210 x 1245 x 700 1340 x 900 x 320
inch 8-9/32 x 49-1/64 x 27-9/16 52-7/8 x 35-7/16 x 12-19/32
Net Weight kg (lbs) 33 (73) 110 (242)
Piping
Connection
Refrigerant
Gas mm (inch) O.D Ø 15.88 (5/8) Flared Type
Liquid mm (inch) O.D Ø 9.53 (3/8) Flared Type
Drain mm O.D Ø 20 I.D Ø 20 x 1
Compressor Type, Number of Set - Hermetic - 2P (Rotary), 1
Starting Method - DC - INV control
Motor
Type - 4-pole single phase brushless motor
Rated Output kW - 3.8
Fan Type, Number of Set Sirocco fan-4 Mix flow fan - 1
Motor
Type 4-pole single phase induction motor 6-pole single phase induction motor
Rated Output kW 0.04 x 2 0.07 x 2
Air-heat Exchanger (Row x Stage x FPI) Slit-fin type (2 x 12 x 18) Corrugate-fin type (2 x 51 x 18)
Refrigerant Control - Exp. Valve
Refrigerant Oil (Charged)
cm
3
- FV50S (1200)
Refrigerant (Charged) R410A kg (oz) - 3.50 (123)
Running
Adjustment
Control Switch Wireless or Wired Remote Control -
Room Temperature Thermostat -
Safety Devices Temperature, current and pressure protection control for compressor,
Internal thermostat for FM, High pressure switch,
Current trans, Crankcase heater
Noise Level dB (A) Hi 45 Lo 41 Cooling 55, Heating 57
Power level dB
Cooling : Hi 62 Lo 58
Heating : Hi 62 Lo 58
Cooling 69, Heating 71
Moisture Removal L/h (Pt/h) 9.0 (19.0)
EER W/W 2.91
COP W/W 3.34
ITEM / MODEL Condition by JIS-B8615
Volts V 240
Phase Single
Power Consumption kW Cool 4.81
Heat 4.79
Running Current A Cool 21.0
Heat 20.9
Starting Current A 21.0
Power Factor % Cool 95
Heat 95
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power source AC, 1~240V 50Hz
