Panasonic LUMIX DC-GH6 User Manual

Video Settings – Synchronizing the Time Code with an External Device
391
Preparations for Time Code Synchronization
When [Count Up] is set to [FREE RUN] in the [ ] mode, you can
synchronize the initial value of the time code with an external device.
1
Set the recording mode to [ ].
≥Set the mode dial. (ÎSelecting the Recording Mode: 79)
2
Set [Count Up] to [FREE RUN].
≥ ¨ [ ] ¨ [ ] ¨ [Time Code] ¨ [Count Up] ¨ [FREE RUN]
3
Rotate the flash synchro socket cap in the direction of
the arrow to remove.
• Be careful not to lose the flash synchro socket cap.
4
Insert the BNC conversion cable (for TC IN/OUT), and
then rotate the locking screw in the direction of the
arrow to attach the cable.

Panasonic LUMIX DC-GH6 Specifications

General

USB version	3.2 Gen 2 (3.1 Gen 2)
Microphone in	Yes
USB connector	USB Type-C
Headphone outputs	1
HDMI connector type	Full-size
Headphone connectivity	3.5 mm
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
Near Field Communication (NFC)	No
Scene modes	-
Photo effects	Black&White, Sepia
White balance	ATW, AWC, Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modes	Auto, Manual, Program
Self-timer delay	2, 3, 10 s
Diopter adjustment (D-D)	-4 - 3
Display diagonal	3 \
Display resolution	1840000 dot
Display aspect ratio	3:2
Display diagonal (metric)	7.6 cm
Magnification	1.52 x
Viewfinder type	Optical
Viewfinder resolution	3680000 pixels
HD type	5.8K
Video resolutions	3840 x 2160, 4352 x 3264, 5728 x 3024, 5760 x 4320, 1920 x 1080 pixels
Maximum video resolution	5760 x 4320 pixels
Audio system	Mono
Memory slots	2
Compatible memory cards	CFexpress, SD, SDHC, SDXC
Camera shutter type	Electronic
Fastest camera shutter speed	1/32000 s
Slowest camera shutter speed	60 s
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Light metering	Centre-weighted, Evaluative (Multi-pattern), Highlight-weighted, Spot
ISO sensitivity	50, 100, 125, 250, 800, 2000, 12800, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	50
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Number of measurement zones	1728
Battery voltage	7.2 V
Battery capacity	2200 mAh
Focus adjustment	Auto/Manual
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus, Tracking Auto Focus
Product color	Black
Megapixel	25.21 MP
Camera type	MILC
Sensor type	Live MOS
Total megapixels	26.52 MP
Image sensor size	- \
Image formats supported	JPEG, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	11552 x 8672 pixels
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Body
Still image resolution(s)	5776x4336, 4096x3072, 2944x2208, 11552x8672, 8192x6144, 5776x3848, 4096x2728, 2944x1960, 11552x7696, 8192x5464, 5776x3248, 4096x2304, 2944x1656, 11552x6496, 8192x4608, 4336x4336, 3072x3072, 2208x2208, 8672x8672, 6144x6144
Digital zoom	- x

Weight and Dimensions

Depth	99.6 mm
Width	138.4 mm
Height	100.3 mm
Weight	739 g
Weight (including battery)	823 g
