Panasonic LUMIX DMC-GX8 User Manual

9. Recording Motion Pictures
248
Set the frames that determine a focus start (first) position and
focus end (second) position. The camera then measures its
distance to the subjects and sets focus. When you start
motion picture recording, focus shifts from the first frame to
the second frame.
1 Press 2.
2 Press 3/4/2/1 to move the AF area frame, and press [MENU/SET]. (First
position)
•
If you press [DISP.] before pressing [MENU/SET], the frame will return to the center.
3 Repeat step 2. (Second position)
•
Auto Focus will work to set the start and end focus of Pull Focus. When the setup has
failed, the frame returns to the first position. Perform the setup again.
• If you press [MENU/SET], the frame settings will be canceled.
Touch a subject (First position), drag your finger to the desired location (Second
position), and release the finger.
•
Auto Focus will work to set the start and end focus of Pull Focus. When the setup has failed,
the frame returns to the first position. Perform the setup again.
• If you touch [ ], the frame settings will be canceled.
• When [Pull Focus] is set to [ON]:
– Auto Focus Mode will be switched to [ ], a setting specially designed for [Pull Focus].
– If you take a picture, the Auto Focus operation [Ø] will take place at the first frame position.
• To re-adjust the focus while recording a motion picture, press the shutter button halfway after
Pull Focus operation finishes.
• Pull Focus does not work when the two frames are not set.
• Even when [Metering Mode] (P171) is set to [ ], the spot metering target does not move with
focus. The target is fixed at the start position (first position) of Pull Focus.
Not available in these cases:
•
This function is not available in the following cases:
– In Manual Focus
– When using the Digital Zoom
– With lenses that only offer Manual Focus
– With some Four Thirds lenses
Setting up [Pull Focus]
Button operation
Touch operation
• A greater effect can be achieved by creating a striking contrast of focus between
the start and end positions, for example by shifting focus from the background to
foreground, or vice versa.
• After setting focus, try to keep the distance between the subject and the camera
constant.

Panasonic LUMIX DMC-GX8 Specifications

General

Camera type	MILC Body
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	21.77 MP
Image sensor size	- \
Image formats supported	JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	5184 x 3888 pixels
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Body
Still image resolution(s)	5184 x 3888, 3712 x 2784, 2624 x 1968, 1824 x 1368, 5184 x 3456, 3712 x 2480, 2624 x 1752, 1824 x 1216, 5184 x 2920, 3840 x 2160, 1920 x 1080, 1824 x 1024, 3888 x 3888, 2784 x 2784, 1968 x 1968, 1712 x 1712
Digital zoom	- x
Focus	TTL
Focus adjustment	Auto/Manual
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Closest focusing distance	0.3 m
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Flash off, Forced on, Red-eye reduction, Second curtain synchro, Slow synchronization
Flash sync-speed	1/250 s
Flash range (wide)	- m
Shoe mounting point type	Hot shoe
Flash exposure correction	±3EV (1/3 EV step)
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Video formats supported	AVCHD, MP4
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	640x480@30fps, 1280x720@30fps, 1920x1080@30fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@30fps
Audio system	Mono
Memory slots	1
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1040000 pixels
Magnification	0.77 x
Viewfinder type	Electronic
USB version	2.0
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Eye relief	21 mm
Scene modes	Panorama, Portrait, Landscape (scenery)
Image editing	Crop, Rotating
Photo effects	Black&White, Sepia, Vivid
White balance	ATW, Auto, Cloudy, Daylight, Flash, Halogen, Shade
Camera playback	Movie, Single image, Slide show, Thumbnails
GPS (satellite)	No
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3, RAW
Diopter adjustment (D-D)	-4 - 3
Power source type	Battery
Battery voltage	7.2 V
Battery capacity	1200 mAh
Battery life (CIPA standard)	330 shots
Product color	Black
Cables included	USB

Weight and Dimensions

Depth	61.3 mm
Width	133.2 mm
Height	77.9 mm
Weight	435 g
Lens length	63.6 mm
Lens weight	165 g
Lens diameter	60.6 mm
Weight (including battery)	487 g
