Panasonic LUMIX DMC-GX8 User Manual

335
12. Connecting to other equipment
2
Turn on the TV and select the input to match the connector in use.
3
Turn the camera on and then press [(].
• Input of the TV will switch automatically and playback screen is displayed when
connected to a VIERA Link compatible TV using an HDMI micro cable with the [VIERA
Link] set to [ON]. (P336)
• Depending on the [Aspect Ratio], black bands may be displayed on the top and bottom or the
left and right of the pictures.
• Change the screen mode on your TV if the picture is displayed with the top or bottom cut off.
• Output from the HDMI micro cable has priority when both AV cable (optional) and HDMI micro
cable are connected.
• The connection with the USB connection cable (supplied) will take priority when you connect
the USB connection cable (supplied) simultaneously with the HDMI micro cable.
• When you play back a picture vertically, it may be blurry.
• Proper playback will be dependent on the TV used for viewing.
• No sound is output from the camera speakers.
• Read the operating instructions for the TV.
To connect with an AV cable (optional)
•
Always use a genuine Panasonic AV cable (DMW-AVC1: optional).
• Check the [TV Aspect]. (P80)
• Audio will be played back in monaural.
• The viewfinder cannot be displayed when connected with a AV cable.
A HDMI micro cable
B HDMI socket
C AV cable (optional)
D Yellow: to the video input socket
E White: to the audio input socket
F Align the marks, and insert.
G Insert the AV cable so that its [ ] mark
will face the [ ] mark side of the camera.
H Check the terminal.

Panasonic LUMIX DMC-GX8 Specifications

General

Camera type	MILC Body
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	21.77 MP
Image sensor size	- \
Image formats supported	JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	5184 x 3888 pixels
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Body
Still image resolution(s)	5184 x 3888, 3712 x 2784, 2624 x 1968, 1824 x 1368, 5184 x 3456, 3712 x 2480, 2624 x 1752, 1824 x 1216, 5184 x 2920, 3840 x 2160, 1920 x 1080, 1824 x 1024, 3888 x 3888, 2784 x 2784, 1968 x 1968, 1712 x 1712
Digital zoom	- x
Focus	TTL
Focus adjustment	Auto/Manual
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Closest focusing distance	0.3 m
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Flash off, Forced on, Red-eye reduction, Second curtain synchro, Slow synchronization
Flash sync-speed	1/250 s
Flash range (wide)	- m
Shoe mounting point type	Hot shoe
Flash exposure correction	±3EV (1/3 EV step)
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Video formats supported	AVCHD, MP4
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	640x480@30fps, 1280x720@30fps, 1920x1080@30fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@30fps
Audio system	Mono
Memory slots	1
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1040000 pixels
Magnification	0.77 x
Viewfinder type	Electronic
USB version	2.0
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Eye relief	21 mm
Scene modes	Panorama, Portrait, Landscape (scenery)
Image editing	Crop, Rotating
Photo effects	Black&White, Sepia, Vivid
White balance	ATW, Auto, Cloudy, Daylight, Flash, Halogen, Shade
Camera playback	Movie, Single image, Slide show, Thumbnails
GPS (satellite)	No
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3, RAW
Diopter adjustment (D-D)	-4 - 3
Power source type	Battery
Battery voltage	7.2 V
Battery capacity	1200 mAh
Battery life (CIPA standard)	330 shots
Product color	Black
Cables included	USB

Weight and Dimensions

Depth	61.3 mm
Width	133.2 mm
Height	77.9 mm
Weight	435 g
Lens length	63.6 mm
Lens weight	165 g
Lens diameter	60.6 mm
Weight (including battery)	487 g
