4
Operation Panel
•
Operation panel of
the NA-F75S6
ECONAVI lamp
(P. 5)
Auto Restart lamp
In case of a
power failure
during operation,
operation will
resume from
the point where
it was stopped
when the power is
recovered.
The lamp lights up
when the operation
resumes.
Power On/Off
The power turns
off automatically if
you do not press
“Start”/“Pause”
within 10 minutes
after power-on.
Change water level
During the wash process,
press “Water Level” to
change the water level.
● Some water levels
cannot be selected
depending on the
program.
● When the remaining
time is displayed, press
“Water Level” to check
the water level.
Detergent volume
The detergent volume
guideline corresponding to
the water level indication is
shown below.
(
: 1 scoop of detergent)
Detergent volume
Water level
Water level/
remaining time
Indicates the selected program
(No.)
After starting operation, indicates
the water level according to the
amount of laundry.
Indicates the approximate
remaining time (min).
Wash / Rinse / Spin (P. 11) Program selection (P. 6)
Child Lock lamp
(P. 12)
Start/Pause
Reserve
Set the time to fi nish washing
(in hours).
e.g.) 8 hours later
● Setting range: 2 - 24 hours later,
in one-hour increments.
(3 - 24 hours later for the Power
Soak program)
● Not available for the following
programs:
Gentle Hand Wash
Delicate
Air Dry
Tub Hygiene
Temp Setting
For washing, cold water can be mixed with
hot water. Press the button to select Hot/
Warm. (P. 9)
Do not use water hotter than 60 °C.
● The estimated water temperature in the
tub during wash process (when hot water
is 50 ºC, and cold water is 20 ºC):
Hot approx. 40 ºC
Warm approx. 30 ºC
● Lamp indications
Lighted: Hot/Warm is set.
Flashing: Hot water is being supplied.
Unlit: Cold is set.
● Not available for the following programs:
Gentle Hand Wash
Delicate
Air Dry
Tub Hygiene
To Next Page
