9
Before Use
Quick Guide
Insert the Battery Pack
Insert Cassette
1 Insert the Battery Pack and slide
it up until it locks with a click.
1 Press LCD-OPEN to unlock the LCD
monitor, and swing it fully open.
3 Slide TAPE EJECT to open
the Cassette Compartment
Cover.
Before you begin
• Charge the Battery. (p. 11)
2Set POWER to VCR or
CAMERA.
12
These Palmcorders are equipped with the Easy Cassette Eject System so
it is easy to insert or remove tapes, even when on a tripod. (p. 7)
4 Insert a cassette record tab
up, window side facing out.
• Make sure the record tab
is closed. (p. 6)
5 Press PUSH CLOSE mark to
close the Cassette
Compartment Cover.
DV52.p 9-11.p65 02/05/28, 10:359
To Next Page
