Magellan 13
Programming Chime Zones
(MG32LED & MG10LEDV/H - Hardwired Keypad Modules only)
A Chime-enabled zone will advise you every time it is opened by causing your keypad to beep.
Each keypad must be Chimed separately.
Keypad Muting
When muted, the keypad will only emit the confirmation beep, rejection beep, and beep when a key is pressed. Therefore, when muted,
the keypad will not beep during an alarm and will not beep for chime enabled zones.
Press and hold the [
CLEAR] key for 6 seconds to enable or disable Keypad Muting. If the keypad emits a confirmation beep, Keypad
Muting is enabled for that keypad. If the keypad emits a rejection beep, the feature is disabled.
Each keypad must be muted separately.
Keypad Backlight
The illumination level behind the keys can be modified to suit your needs. There are four backlight levels. The [S] or [MEM] key is used
to set the desired level. Each consecutive push of the [
S] or [MEM] key will increase the backlight level until the maximum level is
reached. After reaching the maximum level, the backlight level will return to the lowest level and the whole process is repeated.
PGM Keys (Programmable Outputs)
Your Magellan system may include one or more programmable outputs (PGMs). When a specific event or condition occurs in the system,
The PGM can be used to reset smoke detectors, activate light switches in your home or office, open/close garage doors and much more.
If programmed by your installer, you can press and hold keys [1] & [2], [2] & [3], [4] & [5], [5] & [6], [7] & [8], or [8] & [9] for each
respective PGM. Press and hold [
CLEAR] + [ENTER] or [] for three seconds to perform a smoke reset. These features must be set by
your installer.
How do I chime zones? MG32LED (32-zone Hardwired LED Keypad Modules only)
1. Press & hold the [
T] key for 3 seconds. The Arm1, Arm2, Stay1, and Stay2 LEDs will flash.
2. Select the numbers corresponding to the zones you want to Chime by entering the two-digit zone number. For example, to chime
zone 2 enter [0] then [2]. The corresponding LED will light up. The keypad will automatically save the information once the 2-digit
zone number is entered.
3. Press the [ENTER] key to exit.
To remove the Chime feature from a zone, in step 2 enter the zone number again so the number extinguishes or press [
SLEEP] to
remove Chiming from all zones programmed to Chime. Any zones that are already Chimed will also illuminate. Zones that remain unlit
are not Chimed.
How do I chime zones? MG10LEDV/H (10-zone LED Keypad Modules only)
1. Press & hold the zone key ([1] to [0(10)]) for 3 seconds. Accept beep = Chime on, Fail beep = Chime off.
How do I modify the backlight? MG32LED / MG32LRF (32-zone Hardwired & Wireless LED Keypad Modules only)
1. Press and hold the [S] key for 3 seconds.
2. Press the [
S] key to set the desired backlight level.
3. Press [
CLEAR] or [ENTER] to exit.
How do I modify the backlight? MG10LEDV/H (10-zone LED Keypad Modules only
1. Press and hold the [
MEM] key for 3 seconds. The [MEM] key will illuminate.
2. Press the [
MEM] key to set the desired backlight level.
3. Press [
CLEAR] or [ENTER] to exit.
