Parkside PABS 16 A1 Translation Of The Original Instructions

7
PABS 16 A1
GB
Changing tools
Your cordless drill has a fully automatic spindle
lock
.
When the motor is stopped, the power train is locked
so that the chuck
can be opened by turning .
After you have attached the desired tool and tight-
ened it by turning the chuck
, you can continue
working. The spindle lock is automatically released
when the motor starts (ON/OFF switch pressed
).
Torque selection ring/drill setting
You can set the torque using the torque selection
ring
.
♦ Select a low level for small screws or soft
materials.
♦ Select a high level for large screws, hard materials
or removing screws.
♦ Select the drill setting for drilling work by adjusting
the torque selection ring to the position
.
2 speed gearbox
CAUTION!
► Only operate the speed selection switch
when the appliance is at a standstill. Other-
wise the appliance can be damaged.
In first gear (speed selector switch
in
position: 1)
you can reach a speed of approx. 400 rpm and
a high torque. This setting is suitable for all screw-
driving.
In second gear (speed selector switch
in
position: 2)
you can reach a speed of approx. 1300 rpm
for carrying out drilling work.
Operation
Switching on and off
Switching on:
♦ To start the appliance, press the ON/OFF
switch
and keep it pressed in.
The LED work light illuminates when the
ON/OFF switch is depressed even lightly.
This allows illumination of the work area in low
lighting.
Switching off:
♦ Release the appliance's ON/OFF switch
to
switch off the appliance.
Adjusting the rotational speed
Pressing the ON/OFF switch lightly yields a low
speed. Increasing pressure increases the speed.
NOTE
► The integrated motor brake ensures rapid
stoppage.
Changing the direction of rotation
♦ Change the direction of rotation by pressing the
rotational direction switch towards the left
or right.
