Oil tank capacity 0.4 l
Cutting height adjustment 30-66 mm/3 stages
Grass collection basket
capacity
35 l
Cutting width 39 cm
Weight 16.3 kg
Subject to technical changes!
Noise and vibration
WARNING
Noise can have serious effects on your health. If the ma-
chine noise exceeds 85 dB, please wear suitable hearing
protection for you and persons in the vicinity.
Noise data
Sound pressure level L
pA
80.7 dB
Measurement uncertainty K
pA
3 dB
Sound power level L
wA
94 dB
Measurement uncertainty K
wA
1.79 dB
If necessary, adhere to rest periods and limit the duration of
work to the bare minimum.
Vibration parameters
Vibration a
hv
7.218 m/s²
Measurement uncertainty K
h
1.5 m/s²
Keep the noise level and vibration to a minimum!
• Only use faultless products.
• Maintain and clean the product at regular intervals.
• Adapt your working methods to the product.
• Do not overload the product.
• Have the product checked if necessary.
• Switch the product off if it is not in use.
• Wear gloves.
WARNING
In case of extended working periods, the operating person-
nel may suffer circulatory disturbances in their hands (vibra-
tion white finger) due to vibrations.
Raynaud's syndrome is a vascular disease that causes the
small blood vessels on the fingers and toes to cramp in
spasms. The affected areas are no longer supplied with suf-
ficient blood and therefore appear extremely pale. The fre-
quent use of vibrating products can cause nerve damage in
people whose circulation is impaired (e.g. smokers, diabet-
ics).
If you notice unusual adverse effects, stop working immedi-
ately and seek medical advice.
Observe the following information to reduce hazards:
• Keep your body and especially your hands warm in cold
weather.
• Take regular breaks and move your hands to promote
circulation.
• Ensure as little vibration as possible of the product via
regular maintenance and stable parts on the product.
8 Unpacking
• Open the packaging and carefully remove the product.
• Remove the packaging material, as well as the packaging
and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. Immediately report any damage to the transport
company that delivered the Product. Later claims will not
be recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the op-
erating manual before using for the first time.
• With accessories as well as wearing parts and replace-
ment parts use only original parts. Spare parts can be
obtained from your specialist dealer.
• When ordering please provide our article number as well
as type and year of manufacture for the product.
ATTENTION
The product and the packaging material are not
children's toys! Do not let children play with plas-
tic bags, films or small parts! There is a danger of
choking or suffocating!
9 Assembly
CAUTION
Danger of injury due to rotating blade. Only work on the
product when the blade is switched off and stationary!
Some parts of the delivery come disassembled. For quick and
easy assembly, read and follow the instructions below.
NOTE
During assembly and maintenance work, the following ad-
ditional tools are required:
• Oil collecting tray, flat (for oil change)*
• 1 litre measuring beaker (oil / petrol-proof)*
• Fuel canister*
• Funnel*
• Cloth*
• Fuel extraction pump*
• Oil can with hand pump*
• Pliers*
• Phillips screwdriver*
• Open-end wrench/socket spanner*
* = not included in the scope of delivery!
9.1 Installation of the lower push bar (6)
(Fig. 3)
ATTENTION
Ensure that the throttle cable is not squeezed when mount-
ing the push bars.
1. Fit the two lower push bars (6) in the holes provided.
6 | GB / IE / NI / CY / MT
