cial use.
The equipment is designed for use by
adults. Young people under the age of 16
are permitted to use the equipment only
under supervision.
The manufacturer shall not be liable for
damages caused by use other than for the
intended purpose or by incorrect opera-
tion.
General description
The illustrations can be found
on the front and rear fold-out
pages.
Scope of delivery
Unpack the equipment and check that it is
complete. Dispose of the packaging mate-
rial correctly.
- Appliance
- Transparent spark protection (
1)
- Adjusting screw for spark protection
(
2) (1 cross-drive screw incl. spring
washer and washer as well as nut)
- 2 workpiece supports (
6/18) with
mounting material (2 star grip nuts
(
5/17), 2 screws, 2 washers,
2toothed lock washers
- Instruction Manual
Function description
The bench grinder with belt sander is a
combined device equipped with a grinding
disc and an adjustable grinding belt. The
device is provided with a spark protection
and protective hoods for the protection of
the user.
For the function of the operating parts,
please refer to the descriptions below.
Summary
1 Spark protection (two-piece)
2 Adjusting screw for spark protec-
tion
3 Protective hood grinding disc
4 Engine housing
5 Star grip nut to install the work-
piece support grinding belt
6 Workpiece support grinding belt
7 Clamping lever grinding belt
8 Clamping screw for upper belt
idler
9 Protective hood grinding belt
10 Grinding belt
11 Fixing screws for grinding disc
cover
12 Grinding disc cover
13 Bore holes for table mounting
14 On/off switch
14a On switch
14b Off switch
15 Fixing screws for grinding disc
cover
16 Grinding disc cover
17 Star grip nut to mount/adjust the
workpiece support grinding disc
18 Workpiece support grinding disc
19 Grinding disc
20 Upper (a) and lower (b) roller
21 Adjusting screw tape run
