PARTS LIST
- 11 -
POWER AMP ASSEMBLY
CAPACITORS
C1, C2 CC 50V 0.1µF 10% AT 150F-104K-2-FC
C3-C5 CE 50V 2.2µF 20% RL 5x11 157F-225M-5-IU
C6 CC 50V 100pF 10% AT 3.5x 150F-101K-2-FC
C8 CE 50V 22µF 20% RL 5X11 157F-226M-5-IU
C9 CE 50V 2.2µF 20% RL 5x11 157F-225M-5-IU
C10 CC 50V 100pF 10% AT 3.5x 150F-101K-2-FC
C11-C13 CC 50V 0.1µF 10% AT 150F-104K-2-FC
C14 CE 63V 2200µF 20% RL 157I-228M-5-&&
C15 CE 63V 220µF 20% RL 157I-227M-5-S9
C16 CC 50V 0.1µF 10% AT 150F-104K-2-FC
C17 CC 50V 0.047µF 10% AT 150F-473K-2-FD
C18 CC 50V 10pF 5% AT 3.5x2 150F-100J-2-FC
C19 CM 100V 0.22µ 5% RL 8X9 153H-224J-5-OQM
C21 CC 50V 0.1µF 10% AT 150F-104K-2-FC
C20 CC 1000V 0.01µF +/-20% RL 8910-0484-0
C22 CC 50V 100pF 10% AT 3.5x 150F-101K-2-FC
C23 CC 50V 0.1µF 10% AT 150F-104K-2-FC
C24 CC 50V 100pF 10% AT 3.5x 150F-101K-2-FC
C25 CC 50V 0.1µF 10% AT 150F-104K-2-FC
C26 CE 50V 22µF 20% RL 5X11 157F-226M-5-IU
C27 CC 50V 0.1µF 10% AT 150F-104K-2-FC
C28 CE 63V 2200µF 20% RL 157I-228M-5-&&
C29 CE 63V 220µF 20% RL 157I-227M-5-S9
C30 CC 50V 0.1µF 10% AT 150F-104K-2-FC
C31 CC 50V 100pF 10% AT 3.5x 150F-101K-2-FC
C32 CE 50V 22µF 20% RL 5X11 157F-226M-5-IU
C33 CC 50V 39pF 5% AT 3.5x2 150F-390J-2-FC
C34 CM 100V 0.1µF 10% RL 153H-104K-5-QUA
C36 CE 50V 2.2µF 20% RL 5x11 157F-225M-5-IU
C35 CC 50V 39pF 5% AT 3.5x2 150F-390J-2-FC
C38, C39 CC 50V 0.047µF 10% AT 150F-473K-2-FD
C40 CC 50V 0.1µF 10% AT 150F-104K-2-FC
C41 CC 1000V 0.01µF +/-20% RL 8910-0484-0
C42 CE 35V 1000µF 20% RL 157Q-108M-5-X9E
C43 CE 50V 220µF 20% RL 157F-227M-5-S5
C44 CE 35V 1000µF 20% RL 157Q-108M-5-X9E
C45 CE 50V 220µF 20% RL 157F-227M-5-S5
C46 CE 50V 1000µF 20% RL 157F-108M-5-W9
C47 CE 50V 22µF 20% RL 5X11 157F-226M-5-IU
C48 CE 35V 1000µF 20% RL 157Q-108M-5-X9E
C49 CC 50V 0.1µF 10% AT 150F-104K-2-FC
C50 CC 50V 0.015µF 10% AT 150F-153K-2-FD
C51, C52 CE 50V 22µF 20% RL 5X11 157F-226M-5-IU
C53 CC 50V 0.015µF 10% AT 150F-153K-2-FD
C54 CC 50V 180PF 10% AT 150F-181K-2-FC
C55 CE 50V 2.2µF 20% RL 5x11 157F-225M-5-IU
Ref. NO. Description Mfr’s Part No.
