Peavey CS 200X User Manual

STEREO MODE - BALANCED INPUTS
Ground Lift
Defeated
Can be used as
outputs to patch to
other power amp
inputs provided
stereo patch cords
are used
Mode Switch
In Stereo Position
Speakers
oy_ /)q, *
6O*j PEl”t”~ltCIPONICSCoRP * 8 10
16OW.lib ML”,“,IIN MI MI”LINY,A
WMI
Speakers
Set impedance
selector switch
to match load
impedances
t
Right
output
From Mixer
t
Left
output
From Mixer
If hum is Can be used as
oresent in
outouts to patch to
system, the
other pow’er amp
STEREO MODE - UNBALANCED INPUTS
ground lift
inputs with single
feature might conductor shielded
eliminate it
patch cords
Mode Switch
I -
In Stereo Position
I
Set impedance
selector switch
to match load
impedances
t
Right
output
From Mixer
t
Left
output
From Mixer
TWO CHANNEL MONO MODE
If hum is present in
system, the ground lift
feature might eliminate it
I
Mode Switch
In Stereo Position
I
To Second
Set of
To First Set 1
Set impedance
selector switch
I
Speakers
of Speakers
to match load
impedances
BRIDGE MODE
If hum is present in
system, the ground lift
feature might eliminate it
I
Mode Switch
In Bridge Position
System Load
4 ohm minimum
Set impedance selector
switch to match load
imoedances
x indicates not used
t
output
From Mi...
9
