Perlick SIGNATURE SOTTILE Series Service Manual

Models: HC24RS, WS
Temperature Control: Electro-mechanical
Defrost Style: Off cycle defrost
Cabinet Lighting: Lights are controlled through a manual on/off switch as well as
through the door switch.
LOAD COOLING MODE OFF MODE DEFROST MODE
Compressor Energized De-Energized N/A
Condenser Fan Energized De-Energized N/A
Evaporator Fan Energized Energized N/A
Models: HD24RS, WS
Temperature Control: Electro-mechanical
Defrost Style: Off cycle defrost
Cabinet Lighting: Lights are controlled through a manual on/off switch as well as
through the door switch.
LOAD COOLING MODE OFF MODE DEFROST MODE
Compressor Energized De-Energized N/A
Condenser Fan Energized De-Energized N/A
Evaporator Fan Energized De-Energized N/A
Models: HH24BO, BS, RO, RS, WO, WS
Electronic Control: Dixell (XR20CX)
Defrost Style: Off cycle defrost
Cabinet Lighting: Lights are controlled through a manual on/off switch as well as
through the door switch.
Evaporator Fan: Is controlled by the door switch during Cooling Mode
LOAD COOLING MODE OFF MODE DEFROST MODE
Compressor Energized De-Energized N/A
Condenser Fan Energized De-Energized N/A
Evaporator Fan Energized De-Energized N/A
Return to Table of Contents
Residential Refrigeration
and Front Venting Commercial Refrigeration
Service Manual
Table 8-9. HD24RS, WS Load Operation Modes
Table 8-10. HH24BO, BS, RO, RS, WO, WS Load Operation Modes
Electrical System Repair Instructions Page 8-20
Table 8-8. HC24RS, WS Load Operation Modes
