4.3 Technical specifications ATEX
Worm gear screw jack for use in spaces with explosion hazards are designed based on the
environmental influences (ATEX checklist) that have been given to us. The technical specifications and
ATEX terms and conditions specified in the order confirmation must be adhered to. The manufacturer of the
total system needs to evaluate the suitability according to the identification.
The declaration of conformity, in accordance with guideline 2014/34/EC, is rendered void if the
technical data and ATEX conditions are not adhered to
4.3.1 Worm gear screw jacks SHE for explosive-atmosphere zones in acc. with 2014/34/EC (ATEX)
Model series SHE unit size
BG 1.1 3.1 5.1 15.1 20.1 25
Max. lifting capacity dyn/stat [kN] 10 30/45 50/75 100/150 200 250
Max. tensile load dyn/stat [kN] 10 30/45 50/75 99 178/200 250
Screw Tr5 24x5 30x6 40x7 60x12 70x12 90x16
Ratio N 5:1 6:1 6:1 7 2/3:1 8:1 10 2/3:1
Lift per rotation at ratio N [mm/U] 1,0 1,0 1,167 1,565 1,50 1,50
Ratio L 20:1 24:1 24:1 24:1 24:1 32:1
Lift per rotation at ratio L [mm/U] 0,25 0,25 0,292 0,50 0,5 0,5
Max. drive capacity at 20°C ambient temperature and 20%
DC/h
[kW] 0,18 0,33 0,7 1,4 2,0 2,5
Max. drive capacity at 20°C ambient temperature and 10%
DC/h
[kW] 0,35 0,65 1,15 2,7 3,8 5,0
Overall efficiency ratio N [%] 29 27 24 27 24 22
Overall efficiency ratio L [%] 20 19 16 17 17 15
Spindle efficiency [%] 43 40 36,5 39,5 37,5 36,5
Torque-capacity-speed at 20% DC/h and 20°C See power table compendium on worm gear screw jacks
Screw torque at max. lifting force [Nm] 18,4 60 153 702 1009 1725
Max. permit. torque on the drive shaft [Nm] 29,4 46,5 92 195 280 480
Max. permit. screw length at pressure load [mm] See offset diagram compendium worm gear screw jacks
Model series SHE unit size
BG 35 50.1 75 100.1 150.1 200.1
Max. lifting force [kN] 350 500 750 800/1000 1500 2000
Max. tension [kN] 350 500 750 800/1000 1500 -
Screw Tr 100x16 120x16 140x20 160x20 190x24 220x28
Ratio N 10 2/3:1 10 2/3:1 12:1 12:1 19:1 17,5:1
Lift per rotation at ratio N [mm/U] 1,50 1,50 1,667 1,667 1,263 1,60
Ratio L 32:1 32:1 36:1 36:1 -
Lift per rotation at ratio L [mm/U] 0,5 0,5 0,556 0,556 -
Max. drive capacity at 20°C ambient temperature and 20%
DC/h
[kW] 3,0 3,8 4,5 6,5 9,5
Max. drive capacity at 20°C ambient temperature and 10%
DC/h
[kW] 6,0 7,4 9,0 12,5 18,5
Overall efficiency ratio N [%] 21 15 18 15 15
Overall efficiency ratio L [%] 14 10 12 9 -
Spindle efficiency [%] 34 30 31,6 28,5 28,8 29
Torque-capacity-speed at 20% DC/h and 20°C See power table compendium on worm gear screw jacks
Screw torque at max. lifting force [Nm] 2600 4235 7550 11115 19850
Max. permit. torque on the drive shaft [Nm] 705 840 2660 2660 4260
Max. permit. screw length at pressure load [mm] See offset diagram compendium worm gear screw jacks
