Stand assembly
× 4
× 2
M5 x 0.472” (12mm)
M4 x 0.472” (12mm)
Attaching the base
You must attach the base to the unit to have it as a table top unit.
Be sure the front and rear of the base match the proper direction. For large
screen TVs, at least 2 people are required for these steps.
1
2
× 4
M4 x 0.472” (12mm)
Note(s)
•
Make sure to use a table which can support the weight of this unit and is larger than this unit.
•
Make sure the table is in a stable location.
•
A Phillips-head screwdriver is required to fasten the stands to the TV set.
•
When attaching the base, ensure that all screws are tightly fastened. If the base is not properly
attached, it could cause the unit to fall, resulting in injuries as well as damage to the unit.
•
To remove the base from this unit, unscrew the Phillips-head screws by reversing the procedure.
Be careful not to drop the base when you remove it.
Installing the remote control batteries
1
Slide the battery cover off the back of the remote control.
2
Insert two batteries (AAA, 1.5V). Be sure the + and – ends of the
batteries line up with the markings inside the case.
3
Slide the cover back into position.
Note(s)
•
Remove the batteries if not using the remote control for an extended period of time.
9 .English
Continued on next page.
