Philips PET741 User Manual

12
4 Use your player
Turn on
Slide the POWER ON / OFF switch to the ON position.
The
»
PWR indicator turns on.
Select OSD language
You can choose a diffrent language for the on-screen display text.
1
Press SETUP .
The setup menu appears.
»
2
Select [General Setup Page] > [OSD Language] .
3
Press to select an option.
4
Press / OK to confi rm.
5
Press SETUP to exit.
Play discs
1
Slide OPEN on the player.
2
Insert the disc with label side facing up.
3
Push down to close the disc compartment.
Play starts automatically. If not, press
»
/ OK .
If a menu appears, select an item, then press •
/ OK to start play.
To pause, press •
/ OK . Press again to resume play.
To stop, press • STOP
twice.
To select the previous/next item, press •
or .
To start search within video/audio, press •
or once or more.
EN
PET741_37.indb Sec1:12PET741_37.indb Sec1:12 1/7/2009 9:55:53 AM1/7/2009 9:55:53 AM

Philips PET741 Specifications

Picture and Display

Diagonal screen size	7 inch
Resolution	480(w)x234(H)x3(RGB)
Brightness	120 cd/m²
Contrast ratio	200:1
Effective viewing area	154.1x86.6mm
Response time	30 ms

Sound

Output Power (built-in speakers)	250mW RMS
Output Power (earphone)	5mW RMS
Signal to noise ratio (line out)	>80dB
Signal to noise ratio (earphone)	76dB
Signal to noise ratio (built-in speakers)	>62dB

Connectivity

DC in	9V, 1A
Headphone jack	3.5mm Stereo Headphone
AV output	Composite (CVBS) x1

Power

AC/DC Adaptor	DC 9V, 1A, 110-240v, 50/60Hz
Battery Type	Built-in battery
Battery lifetime	Up to 2hrs

Dimensions and Weight

Master carton dimensions	225 x 270 x 240 mm
Packaging dimensions	230 x 255 x 70 mm
Product dimensions	195 x 38 x 153 mm
Master carton weight	3.6 kg
Product weight	0.71 kg
