English
5
Transmitter (figure 1)
1 IR transmitting LEDs – transmit audio
signal to IR headphone.
2 DC power – connect to the 12 Volt/
200 mA AC/DC adapter.
3 Power switch – power on/off switch.
4 3.5 mm stereo headphone audio
input – connects your IR transmitter to an
audio source.
5 Recharging input – connect the
recharge cable to the input.
6 Controls plate
Headphone (figure 2)
7 IR sensors – to receive IR waves from the
transmitter
8 Power indication – lights up when in use.
9 Power On/Off – slide the switch to the
on or off position to switch the headphone
on/off.
10 Volume – adjust volume to your desired
listening level.
11 Recharging indicator – lights up when
the recharging cable is connected between
the headphone and the IR transmitter.
Completely flat batteries will be fully
charged after about 16 hours.
12 Recharging input (figure 3) – connect
the recharging cable to the transmitter.
The recharging indicator on the headphone
must switch on, indicating that the
headphone is being recharged.
Transmitter power supply
IMPORTANT
Use only Philips SBC CS030/00
12 Volt/200 mA AC/DC adapter.
(For UK version: SBC CS030/05
12 Volt/200 mA AC/DC adapter)
1 Make sure the adapter’s rated voltage
corresponds to the mains socket voltage.
2 Connect the DC connector of the AC/DC
adapter to the 12 Volt DC power input
connector located at the rear of the
transmitter.
3 Connect the 12 Volt/200 mA AC/DC
adapter to the mains socket.
– Always disconnect the AC/DC adapter
if the transmitter is not to be used for
a long period of time.
Controls Installation
Environmental Information
All redundant packing material has been omitted.We have done our best to make the
packaging easily separable into two materials: cardboard and polyethylene
Your unit consists of materials which can be recycled if disassembled by a specialized
company. Please observe the local regulations regarding the disposal of packing
materials, exhausted batteries and old equipment.
