PIAGGIO Beverly Tourer 250ie 2007 User Manual

CAUTION
USED OILS CONTAIN SUBSTANCES HARMFUL TO THE ENVIRONMENT. FOR
OIL REPLACEMENT, CONTACT AN AUTHORISED PIAGGIO SERVICE CENTRE,
AS THEY ARE EQUIPPED TO DISPOSE OF SPENT OILS IN AN ENVIRONMEN-
TALLY FRIENDLY AND LEGAL WAY.
CAUTION
USING OILS OTHER THAN THOSE RECOMMENDED CAN SHORTEN THE LIFE
OF THE ENGINE.
Recommended products
AGIP CITY HI TEC 4T
Engine oil
SAE 5W-40, API SL, ACEA A3, JASO MA Synthetic oil
03_05
Hub oil level (03_05, 03_06)
Check the oil in the rear hub. To check the rear hub oil level, proceed as follows:
1. Rest the vehicle onto its centre stand, on level ground.
2. Unscrew the hub oil dipstick «A», dry it with a clean cloth. Reinsert it and screw it
fully into place.
3. Pull out the dipstick to check that the hub oil level is slightly over the notch indicated
by the arrow in the figure. This is the correct level and it must remain constant at all
times.
4. Screw the dipstick back in, checking that it is locked in place.
38
3 Maintenance

PIAGGIO Beverly Tourer 250ie 2007 Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	244 cc
Fuel System	Electronic fuel injection
Transmission	Automatic CVT
Front Suspension	Telescopic hydraulic fork
Front Tire	110/70-16
Width	760 mm
Seat Height	790 mm
Max Power	22 hp @ 8, 250 rpm
Max Torque	20 Nm @ 6, 500 rpm
Rear Suspension	Dual shock absorbers
Front Brake	Single disc
Rear Brake	240 mm disc
Rear Tire	140/70-14
Length	2, 100 mm
