Pioneer F-208 Service Manual

F-208
15
Mark No. Description Part No. Mark No. Description Part No.
PARTS LIST FOR F-208/HL
MAIN ASSY
SEMICONDUCTORS
IC104 (491.315: 315mA/125V) AEK7003
IC103 NJM78M09FA
IC105 NJM78M56FA
Q205 2SA1048
Q201–Q204 2SC2458
Q102 DTC143ES
D108, D109, D118, D119, D201 1SS254
D116 MTZJ27B
D120 MTZJ39C
D107 MTZJ5.6A
D117 MTZJ6.2A
D121 MTZJ6.8B
D106 MTZJ7.5B
D101–D105, D111–D114 S5688G
D122, D123 S5688G
COILS AND FILTERS
L202 LAU1R0J
TRANSFORMERS
T101 STANDBY TRANSFORMER ATT7037
SWITCHES AND RELAYS
RY101 ASR7023
CAPACITORS
C102 (3300pF/AC125V) ACG7017
C101 (10000pF/AC125V) ACG7020
C201 CCCSL101J50
C106 CEANP101M25
C116, C120 CEANP1R0M50
C110 CEAT101M10
C112 CEAT101M16
C109 CEAT101M35
C108 CEAT101M50
C105 CEAT101M6R3
C107 CEAT102M25
C202 CEAT470M10
C111 CEAT470M25
C117 CEAT471M16
C103, C127–C131, C217, C218 CGCYX103K25
C104, C115 CGCYX104M16
C132 CGCYX223K25
C114, C124–C126 CKCYB103K50
C204, C205 CKCYB392K50
RESISTORS
R117, R120 RF1/4PS4R7J
R111 RS1LMF272J
R112 RS1LMF4R7J
Other Resistors RD1/4PU&&&J
OTHERS
CN201 CONNECTOR 52045-1345
CN202 CONNECTOR 52045-2045
CN203 JACK AKN1006
H1–H4 FUSE CLIP AKR1003
CN101 AC CODE SOCKET RKP1751
JA201 JACK VKB1060
KN101, KN102 EARTH METAL FITTING VNF1084
DISPLAY ASSY
SEMICONDUCTORS
IC301 PDG231A
Q301 DTC143ES
D301–D307 1SS254
COILS AND FILTERS
L302 LAU2R2J
SWITCHES AND RELAYS
S301–S320 ASG1034
S321 ASX7027
CAPACITORS
C304 (0.047F/5.5V) ACH1246
C301 CCCSL101J50
C313–C317 CCCSL680J50
C338–C342 CCPUSL680J50
C306 CEAT221M6R3
C302 CEAT2R2M50
C305 CGCYX103K25
C303 CGCYX104K25
C330, C331, C344, C345 CGCYX223K25
C333 CGCYX473K25
C311, C312, C335–C337 CKPUYB102K50
C309, C310, C343 CKPUYY103M16
RESISTORS
All Resistors RD1/4PU&&&J
OTHERS
CN301 CONNECTOR 52044-0345
CN302 20P CONNECTOR 52044-2045
V301 FL TUBE AAV7068
X301 (8.00MHz) EFOEC8004A4
STANDBY ASSY
SWITCHES AND RELAYS
S401 ASG1034
OTHERS
CN401 CONNECTOR 52044-0345
