5
F-208
(1) EXTERIOR PARTS LIST
Mark No. Description Part No.
1 MAIN ASSY See Contrast table (2)
2 DISPLAY ASSY See Contrast table (2)
NSP 3 STANDBY ASSY AWX7265
4 FM/AM TUNER ASSY AXX7054
5 Power Transformer (T102) See Contrast table (2)
6 Fuse (250mA: FU101) REK-094
7 3P F.F.C /30V (J1) ADD7151
8 13P F.F.C /30V (J2) ADD7152
9 20P F.F.C /30V (J3) ADD7153
10 AC Power cord See Contrast table (2)
NSP 11 Chassis ANA7081
12 Insulator AMR7198
13 Foot REC1263
14 PCB Spacer AEC1372
NSP 15 PCB Mould AMR1525
16 Strain Relief CM-22B
17 FL Panel AAK7654
18 Name Plate PAM1776
19 Rotary Knob AAA7004
20 Hinge Button AAD7521
21 Hinge Button AAD7503
22 Hinge Button AAD7523
23 Bonnet See Contrast table (2)
24 Front Panel AMB7611
NSP 25 Name Label See Contrast table (2)
26 Antenna Label AAX7693
27 Caution Label AAX7695
28 Screw BBZ30P080FCC
29 Screw BPZ30P080FMC
30 Screw IBZ30P180FMC
31 Nut NK90FMC
32 Washer WA65F115M080
33 Fuse (160mA: FU102) REK1014
NSP 34 Switch Label See Contrast table (2)
(2) CONTRAST TABLE
F-208/HL and SDB are constructed the same except for the following:
Mark
HL type SDB type
1 MAIN ASSY AWK7517 AWK7491
2 DISPLAY ASSY AWX7266 AWX7263
5 Power Transformer (T102) ATT7044 ATT7045
10 AC Power cord VDG1061 VDG1058
23 Bonnet ANE7237 ANE7230
NSP 25 Name Label AAL7224 AAL7223
NSP 34 Switch Label not used AAX7694
Part No.
Remarks
Symbol and Description
No.
To Next Page
