19
GM-X1024,GM-X924
Network Unit
Consists of
ISO PCB
A LPF/HPF PCB
B LPF/HPF PCB
A P.A.PCB
B P.A.PCB
Unit Number : HWG0008
(GM-X1024/X1R/UC)
Unit Number : HWG0009
(GM-X924/X1R/UC)
Unit Number : HWG0006
(GM-X924/X1R/EW)
Unit Number : HWG0007
(GM-X924/X1R/ES)
Unit Name : Network Unit
MISCELLANEOUS
IC 501 IC NJM2068S
IC 502 IC NJM2068S
IC 503 IC NJM2068S
IC 504 IC NJM2068S
IC 551 IC NJM2068S
IC 552 IC NJM2068S
IC 553 IC NJM2068S
IC 554 IC NJM2068S
IC 851 IC NJM2068S
IC 861 IC NJM2068S
IC 871 IC NJM2068S
IC 881 IC NJM2068S
Q 103 Transistor 2SK389
Q 104 Transistor 2SA992
Q 105 Transistor 2SC1845
Q 106 Transistor 2SA992
Q 107 Transistor 2SC1845
Q 108 Transistor 2SC1845
Q 203 Transistor 2SK389
Q 204 Transistor 2SA992
Q 205 Transistor 2SC1845
Q 206 Transistor 2SA992
Q 207 Transistor 2SC1845
Q 208 Transistor 2SC1845
Q 303 Transistor 2SK389
Q 304 Transistor 2SA992
Q 305 Transistor 2SC1845
Q 306 Transistor 2SA992
Q 307 Transistor 2SC1845
Q 308 Transistor 2SC1845
Q 403 Transistor 2SK389
Q 404 Transistor 2SA992
Q 405 Transistor 2SC1845
Q 406 Transistor 2SA992
Q 407 Transistor 2SC1845
Q 408 Transistor 2SC1845
Q 711 Transistor 2SC2458
Q 721 Transistor 2SC2458
Q 731 Transistor 2SC2458
Q 741 Transistor 2SC2458
D 101 Diode HZS6L(B1)
D 106 Diode HZS6L(B1)
D 201 Diode HZS6L(B1)
D 206 Diode HZS6L(B1)
D 301 Diode HZS6L(B1)
D 306 Diode HZS6L(B1)
D 401 Diode HZS6L(B1)
D 406 Diode HZS6L(B1)
S 501 Switch(LPF/HPF) CSH1029
S 551 Switch(LPF/HPF) CSH1029
VR 501 Volume 20kΩ(E) CCS1266
VR 502 Volume 10kΩ(A) CCS1265
VR 551 Volume 20kΩ(E) CCS1266
VR 552 Volume 10kΩ(A) CCS1265
RESISTORS
R 103 RD1/4PU223J
R 104 RD1/4PU101J
R 105 RD1/4PU104J
R 106 RD1/4PU101J
R 107 RD1/4PU471J
R 109 RD1/4PU472J
R 110 RD1/4PU621J
R 111 RD1/4PU561J
R 112 RD1/4PU333J
R 203 RD1/4PU223J
R 204 RD1/4PU101J
R 205 RD1/4PU104J
R 206 RD1/4PU101J
R 207 RD1/4PU471J
R 209 RD1/4PU472J
R 210 RD1/4PU621J
R 211 RD1/4PU561J
R 212 RD1/4PU333J
R 303 RD1/4PU223J
R 304 RD1/4PU101J
R 305 RD1/4PU104J
R 306 RD1/4PU101J
R 307 RD1/4PU471J
R 309 RD1/4PU472J
R 310 RD1/4PU621J
R 311 RD1/4PU561J
R 312 RD1/4PU333J
R 403 RD1/4PU223J
R 404 RD1/4PU101J
R 405 RD1/4PU104J
=====Circuit Symbol and No.===Part Name Part No.
--- ------ ------------------------------------------ -------------------------
=====Circuit Symbol and No.===Part Name Part No.
--- ------ ------------------------------------------ -------------------------
5. ELECTRICAL PARTS LIST
NOTE:
- Parts whose parts numbers are omitted are subject to being not supplied.
- The part numbers shown below indicate chip components.
Chip Resistor
RS1/_S___J,RS1/__S___J
Chip Capacitor (except for CQS.....)
CKS....., CCS....., CSZS.....
To Next Page
