Pioneer SC-LX73 Service Manual

2
SC-LX83
1
2 3 4
A
B
C
D
E
F
1
2 3 4
1. EXPLODED VIEWS AND PARTS LIST
CONTRAST TABLE
SC-37/UXJCB, SC-LX83/AXJ5 and SC-LX73/AXJ5 are constructed the same except for the following:
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
5
6 1
4 7 3
R 5 0
1
R 0
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
RN1/4PC F562 x 10
1
5621 5 26 1
Mark No. Symbol and Description SC-37/UXJCB SC-LX83/AXJ5 SC-LX73/AXJ5 Remarks
PCB ASSEMBLIES
NSP 1..AUDIO_COMPOSITE ASSY AWR7090 AWR7100 AWR7100
P107-10 2..AUDIO ASSY AWX9647 AWX9735 AWX9735
P107-12 1..DIGITAL MAIN ASSY AWX9620 AWX9627 AWX9628
P107-13 1..DAC HIGH ASSY AWX9622 AWX9711 Not used
P107-14 1..DAC LOW ASSY Not used Not used AWX9659
P107-15 1..COMPONENT ASSY AWX9654 AWX9654 AWX9656
P109-1 1..ICEPOWER AMP ASSY AWH7024 AWH7031 AWH7033
NSP 1..INTERFACE_REG ASSY AWR7085 AWR7096 AWR7096
P109-4 2..INTERFACE ASSY AWX9605 AWX9701 AWX9701
NSP 1..MIC HP ICE ASSY AWM8190 AWM8245 AWM8244
P107-1 2..ICE BUFFER ASSY AWX9598 AWX9748 AWX9747
NSP 1..PRIM_DISPLAY ASSY AWM8191 AWM8208 AWM8215
P111-3 2..DISPLAY ASSY AWX9600 AWX9685 AWX9692
P109-3 2..PRIMARY ASSY AWX9604 AWX9697 AWX9697
PACKING SECTION
> P103-1 AC Power Cord ADG7111 ADG7105 ADG7105
P103-3 IR Bluster Cable ADF7007 ADF7007 Not used
P103-5 Protection Sheet LX AEH7030 Not used Not used
P103-8 Packing Case AHD8677 AHD8681 AHD8688
P103-11 Operating Instrutions (En) ARB7446 Not used Not used
Operating Instrutions (Zhcn) Not used ARC7958 ARC7958
P103-13 Caution Sheet SP (En) ARM7083 Not used Not used
P103-13 Caution Sheet SP (Zhcn) Not used ARM7104 ARM7104
P103-14 RF Remote Caution ARM7131 ARM7131 Not used
NSP P103-15 Warranty Card ARY7007 ARY7118 ARY7118
P103-16 RF Remote Control Unit AXD7580 AXD7580 Not used
P103-17 Remote Control Unit Not used Not used AXD7592
P103-18 RF Receiver Box AXX7272 AXX7272 Not used
P103-19 Battery Cover AZN8049 AZN8049 Not used
P103-20 Battery Door Not used Not used AZN8047
NSP P103-22 Dry Cell Battery (LR6) VEM1047 VEM1053 Not used
NSP P103-22 Dry Cell Battery (R3) Not used Not used VEM1051
