CONNECTING YOUR SYSTEM
IMPORTANT:Makesureallequipmentisturnedoffbeforemakinganyconnections.
Correctwiringofyourloudspeakersisessentialforachievingthebestsoundquality.Becarefultoensure
properpolarityofconnection.Werecommendaminimumof18gaugeforrunsupto25feet,andthickerfor
longerruns.
Mostloudspeakercableiscodedtoeasethistask.Typicallytheribbedorstripedsideisconnectedtothe
positive(red)terminal.Makesurethattheamplierpositive(red)terminalisconnectedtotheloudspeaker
positive(red)terminal.Stripoff½”ofinsulationfromtheendsofthecable,twistthebarestrandsandinsert
intothebindingposts.Takecarethatnostraystrandsofwireshortacrossbetweentheterminals.
1: Strip the cover and twist the strands
2: Connect each speaker cable (not included) to one set of the receiver’s
speaker output terminals and the speaker input terminals. The red terminal
isthepositive(+),andtheblackterminalisthenegative(–).Makesurethat
thereceiverpositive(red)terminalisconnectedtothespeakerpositive
(red)terminal.
ENGLISH
Fil allant vers la borne
positive du récepteur
Fil allant vers la borne
négative du récepteur
Négative
Positive
Wire going to positive
terminal of receiver
Wire going to negative
terminal of receiver
Negative
Positive
Alambre que va al terminal
positivo del receptor
Alambre que va al terminal
negativo del receptor
Negativo
Positivo
INSTALLING THE BASE TO THE SP-FS52
FLOORSTANDING SPEAKERS
IncludedintheSP-FS52cartonare(1)baseand(4)screws.
Attachthebasetothebottomofthespeakerusing(4)screws,
asillustrated.(Screwdriverisnotincluded.)
INSTALLING AND REMOVING THE GRILL
Thefrontpanelgrillmayberemovedifdesired.Toremove,hold
theloweredgeofthegrillnearthemountingpointswithboth
handsandpullforwardgently,awayfromthespeaker.Repeatas
youworkyourwayupthegrill.Toreplacethegrillonthespeaker,
alignthepegsonthegrillwiththeholesinthespeakerand
press in slowly.
SECURING THE SP-FS52
FLOORSTANDING SPEAKERS
TheSP-FS52speakercomeswithasafetycatchpre-installedonthe
backofthecabinetforsecuringtoawalltoavoidtipping.Screwa
supportinghook(notincluded)intothewallbehindthespeaker.Pass
athickcord(notincluded)aroundthesupportinghookandthrough
thesafetycatchsothatthespeakerisstabilized(makesuretotest
thatitsupportstheweightofthespeaker).Afterinstalling,makesure
thespeakerissecurelyxed.
CAUTION:Thesafetycatchisnotamountingxtureandthespeaker
shouldnotbehungdirectlyfromthewallusingthiscatch.Alwaysuse
acordwhenstabilizingthespeaker.Pioneerdisclaimsallresponsibility
foranylossesordamageresultingfromimproperassembly,installation,
insufcientstrengthoftheinstallationmaterials,misuse,ornatural
disasters.Whenplacingthisunit,ensurethatitisrmlysecuredand
avoid areas where it may be likely to fall and cause injury in the event
ofanaturaldisaster(suchasanearthquake).Donotstandonthe
speakerstandbasetopushorswingthespeaker.Thespeakermay
fallandbreak,orsomeonemaybeinjured.Playcloseattentionto
children around the speaker.
Safety catch
Sufficiently
thick cord
(Not Included)
Supporting Hooks
(Not Included)

Pioneer SP-C22 Specifications

Audio Specifications

frequency range	55 Hz-20 kHz
nominal impedance	6 Ohms
sensitivity	88 dB

Power

maximum input power	90 W
power handling	90 Watt

Speaker Components

woofer size	4” (x2)
tweeter size	1”
cross-over frequency	3 kHz

Weight and Dimensions

dimensions	18-1/8” x 7-1/8” x 8-7/16”
weight	13 lbs 7 oz
