CB ASSY
0: 92L36100201011)
0: 92L36100101011)
B
iPOD PCB ASSY
(92L36600201010)
D
DISPLAY PCB ASSY
(X-HM20: 92L36500201010)
(X-HM10: 92L36500101010)
E
KEY-SWITCH PCB ASSY
(X-HM20: 92L37200201010)
(X-HM10: 92L37200101011)
1/7-
A
7/7
-
When ordering service parts, be sure to refer to "EXPLODED VIEWS and PARTS LIST" or "PCB PARTS LIST".
-
The > mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
-
: The power supply is shown with the marked box.
(X-HM20 ONLY)
G
POWER PCB ASSY
(X-HM20: 92L36800201010)
(X-HM10: 92L36800101010)
To Next Page
